Q20E W/30 Banner Proximity Sensors

Q20E W/30 on Powermatic Associates
Banner
  • Q20E W/30
  • Q20E W/30

Part#:Q20E W/30

Alt. Part#:77797

Manufacturer:Banner

Category:Proximity Sensors

Product Lifecycle:Active

Product description

WORLD-BEAM Q20 Series: Emitter (Red); Range: 12 m; Input 10-30 V dc; Output: No output; 9 m (30 ft) Cable

Product Details

  • Weight
    136.0776 g
  • Country Of Origin
    MX
  • IO Link
    No
  • EPLAN Cabinet Installable
    No
  • DeviceNet
    No
  • Feature: Chemical Resistant
    No
  • Feature: Audible
    No
  • Feature: Hazardous Area
    No
  • Feature: Encapsulated
    No
  • Opposed Mode Emitter/Receiver
    Emitter
  • Barrel Diameter (mm)
    N/A
  • Feature: Timing (Hold/Delay)
    No
  • Indicator
    LEDs
  • Adjustments
    N/A
  • Lens Material
    Acrylic
  • Max Op. Relative Humidity [%]
    95% @ 50°C
  • NEMA Rating
    NEMA 6
  • IP Rating
    IP67
  • Number of Pins
    4
  • Delay at Power-up (ms)
    100
  • Repeatability (µs)
    140
  • Sensing Beam Wavelength
    655
  • Special Feature: Water Detection
    No
  • Quick Disconnect Type
    No QD
  • Output response time (ms)
    N/A
  • Special Feature: Remote Teach
    No
  • Operation
    N/A
  • Special Feature: Intrinsically Safe
    No
  • Max Op. Temp. (°C)
    60
  • Power Supply/Supply Voltage
    10-30 V dc
  • Min Op. Temp. (°C)
    -20
  • Connection
    Cable
  • Sensing Mode (Detailed)
    Emitter
  • Outputs
    N/A
  • Primary Housing Material
    Thermoplastic
  • Max Sensing Distance (mm)
    12000
  • Sensing Mode (General)
    Opposed
  • Housing Style
    Rectangular
  • Power
    DC
  • Sensing Beam
    Visible Red LED
  • Cable Length (m)
    9

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q20E W/30 on Powermatic Associates is $77.00. Order now.


About the product

Banner Engineering Q20E W/30 is a photo-electric sensor designed for through-beam system applications, functioning as an emitter alone within the Q20 series. It operates within an ambient air temperature range of -20 to +60°C and is equipped with a pre-wired 30ft / 9m cable that terminates with bare end flying leads for connection. This sensor offers a sensing distance of 12m and utilizes visible red light with a wavelength of 624 nm. It features a rapid response time of 1ms for turning on and 0.6ms for turning off. The Q20E W/30 is housed in a rectangular, thermoplastic casing and is rated with a degree of protection IP67 NEMA 6, ensuring durability in various environments. It supports a supply voltage range of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc.
