526622 Festo Proximity Sensors

Name: 526622
Brand: Festo

Part#:526622

Alt. Part#:SME-8-SL-LED-24

Manufacturer:Festo

Category:Proximity Sensors

Product Lifecycle:Active

12 in stock

Mar 25, 2025

Product description

proximity sensor SME-8-SL-LED-24 Electric, with reed contact, for drives with T-slot, with M8 plug. Design: for T-slot, Conforms to standard: EN 60947-5-2, Authorisation: RCM Mark, CE mark (see declaration of conformity): to EU directive for EMC, Material

Product Details

Type code
SME
Certification
RCM compliance mark
Measuring principle
Magnetic reed
Reproducibility of switching value
+/- 0.1 mm
Max. output current
500 mA
Symbol
00991619
Note on materials
Free of copper and PTFE RoHS-compliant
Max. switching frequency
500 Hz
Overload protection
Not available
Product weight
5 g
Degree of protection
IP65 IP67
Conforms to standard
EN 60947-5-2
CE marking (see declaration of conformity)
As per EU EMC directive
Switching element function
N/O contact
Min. switching capacity AC
10 VA
Short-circuit protection
no
Connection outlet orientation
Longitudinal
Housing material
Epoxy resin High-alloy stainless steel
Contamination level
3
Ambient temperature
-40 °C ... 60 °C

On time

≤ 0.6 ms

Voltage drop

0 V

Operating voltage range AC

10 V ... 30 V

Reverse polarity protection

Insulation voltage

50 V

Design

for T-slot

Switching output

Contact-based, bipolar

Switch-off time

0.05 ms

Type of mounting

Clamped in T slot Can be inserted in slot lengthwise

Switching status indication

LED yellow

Max. switching capacity DC

10 W

DC operating voltage range

10 V ... 30 V

Electrical connection

3-pin Plug

Tightening torque

0.2 Nm

Surge resistance

0.8 kV

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

526622 Related Documents

526622 DataSheet.pdf

Manufacturer warranty

526622 Festo

Get a quick Quote!

Request a quote, and we will send you price within minutes.

Stock:

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty
