Powermatic Associates Logo

Q20ELQPMA Banner Electronic Components

Q20ELQPMA on Powermatic Associates
Banner

Part#:Q20ELQPMA

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

WORLD-BEAM Q20 Series: Long Range Emitter (IR), Range: 20 m; Input 10-30V dc, Output: No output, 6 in (150 mm) PUR pigtail Euro-style QD

Product Details

  • Connection
    Pigtail PUR QD
  • IO Link
    No
  • EPLAN Cabinet Installable
    No
  • DeviceNet
    No
  • Feature: Audible
    No
  • Feature: Chemical Resistant
    No
  • Feature: Hazardous Area
    No
  • Feature: Encapsulated
    No
  • Feature: Timing (Hold/Delay)
    No
  • Barrel Diameter (mm)
    N/A
  • Opposed Mode Emitter/Receiver
    Emitter
  • Adjustments
    N/A
  • Lens Material
    Acrylic
  • Max Op. Relative Humidity [%]
    95% @ 50°C
  • NEMA Rating
    NEMA 6
  • IP Rating
    IP67
  • Indicator
    LEDs
  • Number of Pins
    4
  • Repeatability (µs)
    140
  • Delay at Power-up (ms)
    100
  • Output response time (ms)
    N/A
  • Special Feature: Remote Teach
    No
  • Special Feature: Intrinsically Safe
    No
  • Operation
    N/A
  • Min Op. Temp. (°C)
    -20
  • Special Feature: Water Detection
    No
  • Quick Disconnect Type
    M12 (Euro)
  • Max Op. Temp. (°C)
    60
  • Power Supply/Supply Voltage
    10-30 V dc
  • Sensing Mode (General)
    Opposed
  • Outputs
    N/A
  • Primary Housing Material
    Thermoplastic
  • Max Sensing Distance (mm)
    20000
  • Housing Style
    Rectangular
  • Sensing Mode (Detailed)
    Emitter
  • Power
    DC
  • Sensing Beam
    Infrared LED
  • Cable Length (m)
    0.15

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Q20ELQPMA Related Documents

Q20 Series Sensor -- Datasheet-1630948826060.pdf
