WLAW360X180DQ on Powermatic Associates
Banner

Part#:WLAW360X180DQ

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Only 4 left in stock. Order Now!

Mar 29, 2025

Product description

Banner Engineering WLAW360X180DQ is an industrial LED area light designed with a diffused window for 1-color Cool White (W) LED illumination. It operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. The dimensions of this task light are L180mm x W360mm, featuring an acrylic diffused window and PBT housing. It comes pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The rectangular-shaped light offers a degree of protection rated at IP67 and IP69K, suitable for surface or wall mounting. It can operate in ambient air temperatures ranging from -20°C to +50°C and includes 1 x digital input (12Vdc / 24Vdc) for color control.

Product Details

  • Modbus RTU
    No
  • Feature: Audible
    No
  • Wireless
    No
  • Pro-Editor Compatible (Discrete)
    No
  • IO Link
    No
  • Feature: Chemical Resistant
    No
  • Feature: Quick Disconnect
    Yes
  • Feature: Hazardous Area
    No
  • Feature: Washdown Rated
    Yes
  • Primary Window Material
    Acrylic Diffused
  • Storage Temp (°C)
    -40 to 70
  • Primary Housing Color
    Gray
  • Min Op. Temperature (°C)
    -20
  • Max Op. Temperature (°C)
    50
  • Physical Dimensions (LxWxH or DxH mm)
    381.4 x 180.1 x 25.8
  • Environmental Rating
    IP67; IP69
  • Illuminated Length (LxWxH mm)
    356.6
  • Supply Voltage
    12-30 V dc
  • Number of Colors / Segments
    1
  • Number of Input Pins/Conductors
    4
  • Color 1 - Wavelength/Color Temp/Coordinates
    6500K (Cool)
  • Quick Disconnect Type
    M12 (Euro)
  • Lumens Color 1
    1430
  • Connection
    Integral QD
  • Product Size (mm)
    Other
  • Animation Option 1
    Solid On
  • Color Option 1
    White
  • Color Technology
    Standard LED
  • Power Source
    DC
  • Mounting Thread
    No Thread
  • Primary Housing Material
    PBT
  • Illumination
    Yes
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Housing Style
    Rectangular
  • Power
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

WLAW360X180DQ Related Documents

WLA 360 X 180Q QD-1630953728860.pdfWLA 360 X 180Q QD-1630953728865.stpWLA Work Light -- Datasheet-1630953728863.pdf
