PS010V-504-2UPN8X-H1141 Turck Pressure Sensors
Part#:PS010V-504-2UPN8X-H1141
Manufacturer:Turck
Alt. Part#:6832679
Product Lifecycle:Active
Get a quick Quote!
PS010V-504-2UPN8X-H1141 Pressure Sensor (Rotatable), 2 PNP/NPN Transistor Switching Outputs
About the manufacturer: Turck is one of the manufacturers that offers Pressure Sensors that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.
Check out the PS010V-504-2UPN8X-H1141 Turck price in the box on the right side or send a quick quote.
Product Details
- Weight 330 g
- Ambient temperature -40…+80 °C
- Pressure transducer material Ceramics Al
2 O3 - Protection class IP67/IP69K
- Medium temperature -40…+85 °C
- Housing material Stainless-steel/Plastic, 1.4305 (AISI 303)
- Design With display
- Communication protocol IO-Link
- Pressure type Relative pressure
- Electrical connection Connector, M12 × 1
- Relative pressure bar -1…10 bar rel.
- Process connection G 1/4” male thread
- Electrical output 2 × switching output
- Relative pressure psi -14.5…145.04 psi rel.
- Operating voltage 18…30 VDC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
PS010V-504-2UPN8X-H1141 Description
Turck PS010V-504-2UPN8X-H1141 is a sensor designed for pressure measurement with a programmable compound pressure sensor feature. It offers a set point range of 1-100% and a reset point range of 0.5-99.5%. The sensor can measure pressure in units of bar, psi, kPa, MPa, and miscellaneous others. It operates within an ambient air temperature range of -40°C to +80°C and features a rotatable housing design. The connection is facilitated by a pre-equipped 4-pin M12 Eurofast QD male connector and a G1/4" (1/4" BSPP) threaded male process port. As part of the PS500 series, it has an IP67 degree of protection and requires a supply voltage of 18-30Vdc, with 24Vdc nominal. The sensor's body is cylindrical, and it can reach a maximum switching frequency of 180Hz. It is constructed from 1.4305 (303) stainless steel for both the housing and wetted parts, with a ceramics Al2O3 pressure transducer and a stainless steel pressure connection. The pressure range it covers is -1 to +10bar (-14.5 to +145psi). It supports the IO-Link communication protocol and offers operating modes of NO (Normally Open) or NC (Normally Closed), which are programmable. Protection functions include short-circuit (pulsed) and reverse polarity. The response time ranges from 50 to 600ms, and it has an analog output of 1 x analog output (4-20mA; can be used as a NPN/PNP digital output). Measurement accuracy includes set point accuracy of +/-0.5% FS, analog accuracy of ≤+/-0.5% FS, with repeatability ≤0.5% of the measuring range, and zero shift/span shift ≤0.15% of the measuring range per °C. The current consumption is 50mA.
Related documents PS010V-504-2UPN8X-H1141 Specs
