MG17416 Schneider Electric Industrial Automation Components

MG17416 on Powermatic Associates
Schneider Electric

Part#:MG17416

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

33 in stock

Apr 4, 2025

Product description

Schneider Electric MG17416 is a Miniature Circuit Breaker (MCB) designed as a supplementary protector within the C60 UL1077 sub-range. It features a rated current of 15A and operates on a single pole (1 Pole(s)) configuration. The rated operating voltage (Ue) for this MCB is 277 V. It offers a short circuit breaking rating of 10kA AIR at 240Vac, 5kA AIR at 277Vac, and 10kA AIR at 65Vdc, with protection extended to 1 Pole(s). The tripping curve for this device is classified as type C.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
