DF102V Schneider Electric Industrial Automation Components

Product Details

• Product Certifications
  IEC UL Recognized CSA CCC EAC DNV-GL
• Standards
  EN/IEC 60947-3 EN/IEC 60269-2 UL 4248-1 CSA C22.2 No 4248-1 EN 45545-2: R22 HL2
• Connections - Terminals
  screw clamp terminals 1 0.00…0.02 in² (1…16 mm²)rigid screw clamp terminals 2 0.00…0.01 in² (1…6 mm²)rigid screw clamp terminals 1 0.00…0.02 in² (1…16 mm²)flexible with or without screw clamp terminals 2 0.00…0.01 in² (1…6 mm²)flexible w
• Short-Circuit Withstand
  120 kA 400 V IEC 60947-3 120 kA 500 V IEC 60947-3
• Product Compatibility
  DF2CA fuse cartridge DF2CN fuse cartridge
• Utilisation Category
  AC-20B IEC 60947-3 DC-20B IEC 60947-3
• Fuse Type
  , gG , aM
• [Ue] Rated Operational Voltage
  690 V AC 690 V DC
• Tightening Torque
  19.47 lbf.in (2.2 N.m) PZ2 19.47 lbf.in (2.2 N.m) flat Ø 5.5 mm
• Quantity Per Set
  Set of 6
• Depth
  2.40 in (61 mm)
• Net Weight
  0.19 lb(US) (0.085 kg)
• Width
  1.38 in (35 mm)
• Height
  3.13 in (79.5 mm)
• Mounting Position
  Vertical +/- 23°)
• Mounting Support
  35 mm symmetrical DIN rail
• Overvoltage Category
  III
• [Ui] Rated Insulation Voltage
  690 V AC
• Power Dissipation In W
  3 W maximum power dissipation by fuse
• Local Signalling
  Blown fuse indication
[Ie] Rated Operational Current
32 A 400 V AC
[Uimp] Rated Impulse Withstand Voltage
6 kV
[Ith] Conventional Free Air Thermal Current
32 A 68 °F (20 °C)
Product Or Component Type
Fuse carrier
Fuse Size
10 x 38 mm
Control Type
Toggle padlockable
Device Short Name
DF10
Product Name
TeSys DF
Poles Description
2P
Range
TeSys
