DFCC1 Schneider Electric Industrial Automation Components

Schneider Electric DFCC1 Fuse carrier, TeSys DF, 1P, 30A, 600VAC, fuse class CC
Schneider Electric

Part#:DFCC1

Manufacturer:Schneider Electric

Product Lifecycle:Active

In-stock parts: 11

Sep 28, 2024

Fuse carrier, TeSys DF, 1P, 30A, 600VAC, fuse class CC

About the manufacturer: Schneider Electric is one of the manufacturers that offers Industrial Automation Components that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the DFCC1 Schneider Electric price in the box on the right side or send a quick quote.

Product Details

  • Connections - Terminals
    screw clamp terminals 1 0.00…0.02 in² (1…16 mm²)rigid screw clamp terminals 2 0.00…0.01 in² (1…6 mm²)rigid screw clamp terminals 1 0.00…0.02 in² (1…16 mm²)flexible with or without screw clamp terminals 2 0.00…0.01 in² (1…6 mm²)flexible w
  • Standards
    UL 4248-1 UL 4248-4 CSA C22.2 No 4248-1 CSA C22.2 No 4248-4
  • Tightening Torque
    17.70 lbf.in (2 N.m) PZ2 17.70 lbf.in (2 N.m) flat Ø 5.5 mm
  • Product Certifications
    UL Recognized CSA
  • Quantity Per Set
    Set of 12
  • Depth
    2.40 in (61 mm)
  • Net Weight
    0.09 lb(US) (0.042 kg)
  • Width
    0.69 in (17.5 mm)
  • Height
    3.13 in (79.5 mm)
  • Mounting Position
    Vertical +/- 23°)
  • Mounting Support
    35 mm symmetrical DIN rail
  • Power Dissipation In W
    3 W maximum power dissipation by fuse
  • [Ui] Rated Insulation Voltage
    600 V AC
  • [Uimp] Rated Impulse Withstand Voltage
    6 kV
  • Short-Circuit Withstand
    200 kA 600 V UL 512
  • [Ie] Rated Operational Current
    30 A
  • Utilisation Category
    AC-20B IEC 60947-3
  • [Ue] Rated Operational Voltage
    600 V AC
  • Poles Description
    1P
  • Product Name
    TeSys DF
  • Control Type
    Toggle padlockable
  • Device Short Name
    DFCC
  • Product Or Component Type
    Fuse carrier
  • Range
    TeSys
  • Fuse Type
    , CC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents DFCC1 Specs

DFCC1 Catalog.pdf
DFCC1 Product Datasheet.pdf
