31310 Festo Directional Control Valves

Product Details

• Lap
  Overlap
• Standard nominal flow rate
  1000 l/min
• Mounting position
  Any
• Symbol
  00991022
• On switching time
  5 ms
• Changeover time
  16 ms
• Pilot air port 14
  G1/8
• Pneumatic connection 1
  G1/8
• Note on materials
  RoHS-compliant
• Pneumatic connection 4
  G1/8
• Width
  26 mm
• Design
  Piston gate valve
• Operating pressure
  -0.9 bar ... 10 bar
• Manual override
  None
• Pilot air supply port
  External
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Temperature of medium
  -10 °C ... 60 °C
• Pilot exhaust air port 82
  M5
• Pilot air port 12
  G1/8
• Seals material
  NBR
Valve function
5/3, pressurized
Nominal width
8 mm
Exhaust air function
With flow control option
Flow direction
Reversible
Switching time off
14 ms
Storage temperature
-40 °C ... 60 °C
Product weight
320 g
Pneumatic connection 5
G1/8
Actuation type
Pneumatic
Pneumatic working port
G1/8
Reset method
Mechanical spring
Type of control
Direct
Pilot pressure
3 bar ... 10 bar
Corrosion resistance class (CRC)
1 - Low corrosion stress
Ambient temperature
-10 °C ... 60 °C
Pneumatic connection 2
G1/8
Width dimension
27 mm
Sealing principle
Soft
Type code
VL
Max. switching frequency
3 Hz
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Pilot medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Type of mounting
Optionally: With through-hole
Pneumatic connection 3
G1/8
Housing material
Die-cast aluminum
