173127 Festo Directional Control Valves

Product Details

• Actuation type
  Electrical
• Standard nominal flow rate
  600 l/min
• Nominal width
  5 mm
• Sealing principle
  Soft
• Type of control
  Pilot-controlled
• Switching time off
  28 ms
• Coil characteristics
  24 V DC: 1.5 W
• Storage temperature
  -20 °C ... 40 °C
• Electrical connection
  Connection diagram form C as per industrial standard, 9.4 mm Rectangular design
• Pneumatic connection 1
  G1/8
• Pneumatic connection 2
  G1/8
• Reset method
  Mechanical spring
• Degree of protection
  IP65
• Manual override
  Detenting via accessory
• Symbol
  00991035
• On switching time
  10 ms
• Vibration resistance
  Transport application test with severity level 1 as per FN 942017-4 and EN 60068-2-6
• Noise level
  75 dB(A)
• Pilot exhaust air port 82/84
  M5
• Pneumatic connection 3
  G1/8
Pneumatic connection 5
G1/8
Width
17.8 mm
Operating voltage
24V DC
Certification
c UL us - Recognized (OL)
Type code
MEH
Mounting position
Any
b-value
0.36
C value
2.55 l/sbar
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Temperature of medium
-5 °C ... 50 °C
Ambient temperature
-5 °C ... 50 °C
Pneumatic connection 4
G1/8
Valve function
5/2, monostable
Operating pressure
2.5 bar ... 8 bar
Exhaust air function
With flow control option
Flow direction
Non-reversible
Pilot pressure
2.5 bar ... 8 bar
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Product weight
105 g
Seals material
HNBR NBR
Lap
Overlap
Pneumatic working port
G1/8
Design
Piston gate valve
Width dimension
18 mm
Pilot air supply port
Internal
Duty cycle
100%
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Pilot medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Type of mounting
With through-hole
Note on materials
RoHS-compliant
Housing material
Die-cast aluminum
