574259 Festo Directional Control Valves

574259 on Powermatic Associates
Festo

Part#:574259

Manufacturer:Festo

Category:Directional Control Valves

Alt. Part#:VUWG-L14-T32C-M-G18

Product Lifecycle:Active

In-stock parts: 52

Dec 7, 2024

pneumatic valve VUWG-L14-T32C-M-G18 Valve function: 2x3/2 closed, monostable, Type of actuation: pneumatic, Valve size: 14 mm, Standard nominal flow rate: 430 l/min, Operating pressure: -0,9 - 10 bar

About the manufacturer: Festo is one of the manufacturers that offers Directional Control Valves that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 574259 Festo price in the box on the right side or send a quick quote.

Product Details

  • Actuation type
    Pneumatic
  • Design
    Piston gate valve
  • Mounting position
    Any
  • Pilot pressure
    3 bar ... 10 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Valve size
    14 mm
  • Reset method
    Mechanical spring
  • Sealing principle
    Soft
  • Symbol
    00992942
  • On switching time
    9 ms
  • Ambient temperature
    -5 °C ... 60 °C
  • Type of mounting
    Optionally: With through-hole
  • Note on materials
    RoHS-compliant
  • Valve function
    2x3/2, closed, monostable
  • Pneumatic working port
    G1/8
  • Width dimension
    16 mm
  • Exhaust air function
    With flow control option
  • Type of control
    Direct
  • Switching time off
    13 ms
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    77 g
  • Pneumatic connection 3
    G1/8
  • Pneumatic connection 4
    G1/8
  • Lap
    Overlap
  • Standard nominal flow rate
    430 l/min
  • Operating pressure
    -0.9 bar ... 10 bar
  • Flow direction
    Reversible
  • Pilot medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Pilot air port 12
    M5
  • Pneumatic connection 5
    G1/8
  • Type code
    VUWG
  • Manual override
    None
  • Suitability for vacuum
    yes
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Pilot air port 14
    M5
  • Pneumatic connection 2
    G1/8
  • Seals material
    HNBR NBR
  • Temperature of medium
    -5 °C ... 50 °C
  • Pneumatic connection 1
    G1/8
  • Housing material
    Aluminum Anodized

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.



Related documents 574259 Specs

This item can ship within 24h!

Manufacturer warranty

$100.52

Stock:

52

Select Qty:

$100.52

$100.52 each

Worldwide Shipping and Delivery


Secure Payment Processing


Warranty


Responsive Customer Support
