533346 Festo Directional Control Valves

Product Details

• Relative air humidity
  Max. 90 % at 40 °C
• Pilot pressure MPa
  0.3 MPa ... 0.8 MPa
• Operating voltage
  24V DC
• Sealing principle
  Soft
• Manual override
  Detenting Non-detenting
• Type of control
  Pilot-controlled
• Standard nominal flow rate with QS-6
  240 l/min
• Changeover time
  15 ms
• Valve function
  5/3, exhausted
• Actuation type
  Electrical
• Certification
  c UL us - Recognized (OL)
• Signal status display
  yes
• On switching time
  10 ms
• Vibration resistance
  Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
• Ambient temperature
  -5 °C ... 50 °C
• Operating pressure
  -0.9 bar ... 10 bar
• Reset method
  Mechanical spring
• Mounting position
  Any
• Symbol
  00991032
• Suitability for vacuum
  yes
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Storage temperature
-20 °C ... 40 °C
Product weight
56 g
Lap
Overlap
Valve size
10 mm
Degree of protection
IP65 as per IEC 60529
Type code
VMPA1
Pilot pressure
3 bar ... 8 bar
Max. positive test pulse with 0 signal
400 µs
Max. negative test pulse on 1 signal
200 µs
Permissible voltage fluctuations
+/- 25 %
Corrosion resistance class (CRC)
1 - Low corrosion stress
Type of mounting
With through-hole
Housing material
Die-cast aluminum
Standard nominal flow rate
240 l/min
Design
Piston gate valve
Flow direction
Reversible
Switching time off
35 ms
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Max. tightening torque for valve mounting
0.25 Nm
Note on materials
RoHS-compliant
Temperature of medium
-5 °C ... 50 °C
Seals material
NBR
