533345 Festo Directional Control Valves

Product Details

• Valve function
  5/3, closed
• Operating pressure
  -0.9 bar ... 10 bar
• Design
  Piston gate valve
• Type code
  VMPA1
• Symbol
  00991020
• Suitability for vacuum
  yes
• Max. positive test pulse with 0 signal
  400 µs
• Changeover time
  15 ms
• Actuation type
  Electrical
• Degree of protection
  IP65 as per IEC 60529
• Mounting position
  Any
• Manual override
  Detenting Non-detenting
• Max. negative test pulse on 1 signal
  200 µs
• Storage temperature
  -20 °C ... 40 °C
• Type of mounting
  With through-hole
• Lap
  Overlap
• Standard nominal flow rate
  320 l/min
• Certification
  c UL us - Recognized (OL)
• Flow direction
  Reversible
• Pilot pressure
  3 bar ... 8 bar
On switching time
10 ms
Permissible voltage fluctuations
+/- 25 %
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Corrosion resistance class (CRC)
1 - Low corrosion stress
Note on materials
RoHS-compliant
Pilot pressure MPa
0.3 MPa ... 0.8 MPa
Reset method
Mechanical spring
Sealing principle
Soft
Signal status display
yes
Switching time off
35 ms
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Temperature of medium
-5 °C ... 50 °C
Max. tightening torque for valve mounting
0.25 Nm
Seals material
NBR
Relative air humidity
Max. 90 % at 40 °C
Valve size
10 mm
Operating voltage
24V DC
Type of control
Pilot-controlled
Standard nominal flow rate with QS-6
320 l/min
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Product weight
56 g
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Ambient temperature
-5 °C ... 50 °C
Housing material
Die-cast aluminum
