8043214 Festo Directional Control Valves

8043214 on Powermatic Associates
Festo

Part#:8043214

Alt. Part#:VUVS-LK20-M52-AD-G18-1C1-S

Manufacturer:Festo

Category:Directional Control Valves

Product Lifecycle:Active

Only 5 left in stock. Order Now!

Mar 15, 2025

Product description

solenoid valve VUVS-LK20-M52-AD-G18-1C1-S Valve function: 5/2 monostable, Type of actuation: electrical, Valve size: 21 mm, Standard nominal flow rate: 550 l/min, Operating pressure: 1,5 - 8 bar

Product Details

  • Actuation type
    Electrical
  • Operating voltage
    24V DC
  • Degree of protection
    IP65 as per IEC 60529
  • Sealing principle
    Soft
  • Pilot air supply port
    Internal
  • b-value
    0.38
  • Valve function
    5/2, monostable
  • Standard nominal flow rate
    550 l/min
  • Reset method
    Pneumatic spring
  • Mounting position
    Any
  • C value
    2.66 l/sbar
  • Duty cycle
    100%
  • Permissible voltage fluctuations
    +/- 10 %
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Electrical connection
    Form C as per EN 175301-803
  • Pneumatic connection 5
    G1/8
  • Piston slide material
    Wrought aluminum alloy
  • Valve size
    21 mm
  • Design
    Piston gate valve
  • Nominal width
    5.2 mm
  • Manual override
    Detenting Non-detenting
  • Flow direction
    Non-reversible
  • On switching time
    17 ms
  • Max. positive test pulse with 0 signal
    2700 µs
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Temperature of medium
    -5 °C ... 50 °C
  • Type of mounting
    Optionally: With through-hole
  • Pneumatic connection 2
    G1/8
  • Seals material
    HNBR NBR
  • Lap
    Overlap
  • Pneumatic working port
    G1/8
  • Exhaust air function
    With flow control option
  • Pilot medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Product weight
    145 g
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Operating pressure
    1.5 bar ... 8 bar
  • Type code
    VUVS
  • Type of control
    Pilot-controlled
  • Symbol
    00991049
  • Switching time off
    22 ms
  • Coil characteristics
    24 V DC: 2.4 W
  • Shock resistance
    Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
  • Ambient temperature
    -5 °C ... 50 °C
  • Pneumatic connection 1
    G1/8
  • Pneumatic connection 4
    G1/8
  • Max. negative test pulse on 1 signal
    1100 µs
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Vibration resistance
    Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
  • Venting hole connection
    Not ducted
  • Pneumatic connection 3
    G1/8
  • Housing material
    Wrought aluminum alloy

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.



8043214 Related Documents

Manufacturer warranty

8043214 Festo

Get a quick Quote!

Request a quote, and we will send you price within minutes.

Stock:

5

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery


Secure Payment Processing


Warranty


Responsive Customer Support

Got Questions? We've Got Answers!


Need more details?

Feel free to chat with us

Compare 8043214 with other products

Actuation type

Operating voltage

Degree of protection

Sealing principle

Pilot air supply port

b-value

Valve function

Standard nominal flow rat...

Reset method

Mounting position

C value

Duty cycle

Permissible voltage fluct...

Corrosion resistance clas...

Electrical connection

Pneumatic connection 5

Piston slide material

Valve size

Design

Nominal width

Manual override

Flow direction

On switching time

Max. positive test pulse ...

Information on operating ...

Temperature of medium

Type of mounting

Pneumatic connection 2

Seals material

Lap

Pneumatic working port

Exhaust air function

Pilot medium

Product weight

Note on materials

Operating pressure

Type code

Type of control

Symbol

Switching time off

Coil characteristics

Shock resistance

Ambient temperature

Pneumatic connection 1

Pneumatic connection 4

Max. negative test pulse ...

Operating medium

Vibration resistance

Venting hole connection

Pneumatic connection 3

Housing material

Pilot pressure MPa

Suitability for vacuum

Certification

Restricted ambient and me...

Pilot pressure

Max. switching frequency

Signal status display

Selected product

8043214
5 in stock
8043214
Festo

solenoid valve VUVS-LK20-M52-AD-G18-1C1-S Valve function: 5/2 monostable, Type of actuation: electri...

Actuation typeElectrical

Operating voltage24V DC

Degree of protectionIP65 as per IEC 60529

Sealing principleSoft

Pilot air supply portInternal

b-value0.38

Valve function5/2, monostable

Standard nominal flow rate550 l/min

Reset methodPneumatic spring

Mounting positionAny

C value2.66 l/sbar

Duty cycle100%

Permissible voltage fluctuations+/- 10 %

Corrosion resistance class (CRC)1 - Low corrosion stress

Electrical connectionForm C as per EN 175301-803

Pneumatic connection 5G1/8

Piston slide materialWrought aluminum alloy

Valve size21 mm

DesignPiston gate valve

Nominal width5.2 mm

Manual overrideDetenting Non-detenting

Flow directionNon-reversible

On switching time17 ms

Max. positive test pulse with 0 signal2700 µs

Information on operating and pilot mediaOperation with oil lubricati...

Temperature of medium-5 °C ... 50 °C

Type of mountingOptionally: With through-hol...

Pneumatic connection 2G1/8

Seals materialHNBR NBR

LapOverlap

Pneumatic working portG1/8

Exhaust air functionWith flow control option

Pilot mediumCompressed air as per ISO 85...

Product weight145 g

Note on materialsContains paint-wetting impai...

Operating pressure1.5 bar ... 8 bar

Type codeVUVS

Type of controlPilot-controlled

Symbol00991049

Switching time off22 ms

Coil characteristics24 V DC: 2.4 W

Shock resistanceShock test with severity lev...

Ambient temperature-5 °C ... 50 °C

Pneumatic connection 1G1/8

Pneumatic connection 4G1/8

Max. negative test pulse on 1 signal1100 µs

Operating mediumCompressed air as per ISO 85...

Vibration resistanceTransport application test w...

Venting hole connectionNot ducted

Pneumatic connection 3G1/8

Housing materialWrought aluminum alloy

Pilot pressure MPa-

Suitability for vacuum-

Certification-

Restricted ambient and media temperature-

Pilot pressure-

Max. switching frequency-

Signal status display-

566496
2 in stock
566496
Festo

solenoid valve VUVG-L14-T32C-AT-G18-1P3 Valve function: 2x3/2 closed, monostable, Type of actuation:...

Actuation typeElectrical

Operating voltage24V DC

Degree of protectionIP40 With plug socket

Sealing principleSoft

Pilot air supply portInternal

b-value-

Valve function2x3/2, closed, monostable

Standard nominal flow rate560 l/min

Reset methodPneumatic spring

Mounting positionAny

C value-

Duty cycle100%

Permissible voltage fluctuations+/- 10 %

Corrosion resistance class (CRC)2 - Moderate corrosion stres...

Electrical connectionVia electrical sub-base

Pneumatic connection 5G1/8

Piston slide material-

Valve size14 mm

DesignPiston gate valve

Nominal width4.6 mm

Manual overrideDetenting Covered

Flow direction-

On switching time9 ms

Max. positive test pulse with 0 signal700 µs

Information on operating and pilot mediaOperation with oil lubricati...

Temperature of medium-5 °C ... 60 °C

Type of mountingOptionally: With through-hol...

Pneumatic connection 2G1/8

Seals materialHNBR NBR

LapOverlap

Pneumatic working portG1/8

Exhaust air functionWith flow control option

Pilot medium-

Product weight89 g

Note on materialsRoHS-compliant

Operating pressure1.5 bar ... 8 bar

Type codeVUVG

Type of controlPilot-controlled

Symbol00992904

Switching time off25 ms

Coil characteristics24 V DC: 1.0 W 24 V DC: low-...

Shock resistanceShock test with severity lev...

Ambient temperature-5 °C ... 60 °C

Pneumatic connection 1G1/8

Pneumatic connection 4G1/8

Max. negative test pulse on 1 signal900 µs

Operating mediumCompressed air as per ISO 85...

Vibration resistanceTransport application test w...

Venting hole connection-

Pneumatic connection 3G1/8

Housing materialWrought aluminum alloy

Pilot pressure MPa0.15 MPa ... 0.8 MPa

Suitability for vacuumno

CertificationRCM compliance mark c UL us ...

Restricted ambient and media temperature-5 - 50 °C Without holding p...

Pilot pressure1.5 bar ... 8 bar

Max. switching frequency-

Signal status display-

8042558
1 in stock
8042558
Festo

solenoid valve VUVG-BK10-T32C-AT-F-1R8L-S Valve function: 2x3/2 closed, monostable, Type of actuatio...

Actuation typeElectrical

Operating voltage24V DC

Degree of protectionIP65

Sealing principleSoft

Pilot air supply portInternal

b-value-

Valve function2x3/2, closed, monostable

Standard nominal flow rate160 l/min

Reset methodPneumatic spring

Mounting positionAny

C value-

Duty cycle100%

Permissible voltage fluctuations+/- 10 %

Corrosion resistance class (CRC)2 - Moderate corrosion stres...

Electrical connection3-pin Plug

Pneumatic connection 5-

Piston slide material-

Valve size10 mm

DesignPiston gate valve

Nominal width-

Manual overrideDetenting Non-detenting

Flow directionNon-reversible

On switching time12 ms

Max. positive test pulse with 0 signal1600 µs

Information on operating and pilot mediaOperation with oil lubricati...

Temperature of medium-5 °C ... 50 °C

Type of mountingOn terminal strip With throu...

Pneumatic connection 2Flange

Seals materialHNBR NBR

LapOverlap

Pneumatic working portFlange

Exhaust air functionWith flow control option

Pilot mediumCompressed air as per ISO 85...

Product weight55 g

Note on materialsContains paint-wetting impai...

Operating pressure1.5 bar ... 7 bar

Type codeVUVG

Type of controlPilot-controlled

Symbol00992904

Switching time off14 ms

Coil characteristics24 V DC: 0.8 W

Shock resistanceShock test with severity lev...

Ambient temperature-5 °C ... 50 °C

Pneumatic connection 1-

Pneumatic connection 4Flange

Max. negative test pulse on 1 signal3000 µs

Operating mediumCompressed air as per ISO 85...

Vibration resistanceTransport application test w...

Venting hole connection-

Pneumatic connection 3-

Housing materialWrought aluminum alloy

Pilot pressure MPa-

Suitability for vacuum-

Certification-

Restricted ambient and media temperature-

Pilot pressure-

Max. switching frequency2 Hz

Signal status displayLED
