Banner SB12TE1 Banner Engineering SB12TE1 is a photo-electric sensor designed for through-beam system applications, part of the SB12 series. This sensor functions as an emitter alone, housed in a thermoplastic with a polycarbonate lens. It features a 12mm diameter and comes pre-wired with a 6.5ft / 2m cable terminated with bare end flying leads. The SB12TE1 operates on a supply voltage range of 10Vdc-30Vdc, with nominal values of 12Vdc and 24Vdc. It is designed for snap-in flush mounting on panels up to 3mm thick. The sensor can operate in ambient air temperatures ranging from -20 to +50°C and is rated IP67 for protection against dust and water ingress. Its shape is an M12 cylindrical threaded/barrel, with a sensing distance of 1.5m. The SB12TE1 emits infrared light and has a response time of 2.5ms / 0.0025 s, with a thread size of M12.
Banner

Part#:SB12TE1

Manufacturer:Banner

Product Lifecycle:Active

In-stock parts: 34

Sep 28, 2024

Banner Engineering SB12TE1 is a photo-electric sensor designed for through-beam system applications, part of the SB12 series. This sensor functions as an emitter alone, housed in a thermoplastic with a polycarbonate lens. It features a 12mm diameter and comes pre-wired with a 6.5ft / 2m cable terminated with bare end flying leads. The SB12TE1 operates on a supply voltage range of 10Vdc-30Vdc, with nominal values of 12Vdc and 24Vdc. It is designed for snap-in flush mounting on panels up to 3mm thick. The sensor can operate in ambient air temperatures ranging from -20 to +50°C and is rated IP67 for protection against dust and water ingress. Its shape is an M12 cylindrical threaded/barrel, with a sensing distance of 1.5m. The SB12TE1 emits infrared light and has a response time of 2.5ms / 0.0025 s, with a thread size of M12.

About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the SB12TE1 Banner price in the box on the right side or send a quick quote.

Product Details

  • Special Feature: Remote Teach
    No
  • Output response time (ms)
    2.5 ON/1.75 OFF
  • Outputs
    N/A
  • Cable Length (m)
    2
  • Power Supply/Supply Voltage
    10-30 V dc
  • Power
    DC
  • Max Sensing Distance (mm)
    1500
  • Primary Housing Material
    Thermoplastic
  • Sensing Mode (General)
    Opposed
  • IO Link
    No
  • DeviceNet
    No
  • Feature: Chemical Resistant
    No
  • Feature: Audible
    No
  • Feature: Hazardous Area
    No
  • Feature: Encapsulated
    No
  • Feature: Timing (Hold/Delay)
    No
  • Opposed Mode Emitter/Receiver
    Emitter
  • Indicator
    LEDs
  • Barrel Diameter (mm)
    12
  • Adjustments
    N/A
  • Lens Material
    Polycarbonate
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • IP Rating
    IP67
  • Number of Pins
    3
  • Repeatability (µs)
    350
  • Delay at Power-up (ms)
    1000
  • Special Feature: Water Detection
    No
  • Max Op. Temp. (°C)
    50
  • Special Feature: Intrinsically Safe
    No
  • Operation
    N/A
  • Min Op. Temp. (°C)
    -20
  • Quick Disconnect Type
    No QD
  • Connection
    Cable
  • Sensing Mode (Detailed)
    Emitter
  • Housing Style
    Barrel
  • Sensing Beam
    Infrared LED
  • Primary brand
    Banner Engineering
  • Functions
    Photo-electric emitter green LED (power ON) yellow LED (light sensed)
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Thread size
    M12
  • Mounting mode
    Snap-in flush mounting (up to 3mm thickness panel)
  • Compliant with standard(s)
    CE
  • Sub-range name
    SB12 series
  • Light Color
    Infrared (IR)
  • Degree of protection
    IP67
  • Supply voltage (DC)
    10Vdc-30Vdc (12Vdc / 24Vdc nom.)
  • Diameter
    12mm
  • Material
    thermoplastic housing Polycarbonate lns.
  • Main function
    Sensor (Photo-electric)
  • Design
    through-beam system / opposed mode
  • Shape
    Cylindrical smooth snap-in mechanism
  • Response time
    2.5ms / 0.0025 s
  • Order code / Manufacturer SKU
    11138
  • Ambient air temperature for operation
    -20...+50 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents SB12TE1 Specs

SB12TE1 SB12T THREADED.pdf
SB12TE1 SB12T THREADED.stp
SB12TE1 SB12T Series Photoelectric Sensor.pdf
