151685 Festo Proximity Sensors

151685 on Powermatic Associates
Festo

Part#:151685

Alt. Part#:SMTO-1-PS-S-LED-24-C

Manufacturer:Festo

Category:Proximity Sensors

Product Lifecycle:Active

Product description

proximity sensor SMTO-1-PS-S-LED-24-C With light emitting diode and integrated protective circuit, without mounting kit. Design: Block design, Authorisation: RCM Mark, CE mark (see declaration of conformity): to EU directive for EMC, Materials note: Free

Product Details

  • Certification
    RCM compliance mark
  • Measuring principle
    Magneto-inductive
  • Symbol
    00991153
  • Note on materials
    Free of copper and PTFE
  • On time
    ≤ 1 ms
  • Voltage drop
    ≤ 3 V
  • Connection outlet orientation
    Longitudinal
  • Housing material
    PC Die-cast zinc
  • Design
    Block design
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Reproducibility of switching value
    +/- 0.1 mm
  • DC operating voltage range
    10 V ... 30 V
  • Electrical connection
    3-pin Plug
  • Degree of protection
    IP67
  • Switching element function
    N/O contact
  • Max. output current
    200 mA
  • Residual current
    ≤ 0.01 mA
  • Type of mounting
    With accessories
  • Product weight
    20 g
  • Type code
    SMTO
  • Ambient temperature
    -25 °C ... 70 °C
  • Switching output
    PNP
  • Max. switching capacity DC
    6 W
  • Short-circuit protection
    Pulsed
  • Max. tightening torque
    0.3 Nm
  • Switch-off time
    ≤ 1 ms
  • Overload protection
    Available
  • Reverse polarity protection
    for all electrical connections
  • Switching status indication
    LED yellow

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
