151694 Festo Proportional Valves

Product Details

• Design
  Piston gate valve
• Flow direction
  Non-reversible
• Symbol
  00995308
• b-value
  0.23
• Nominal width
  8 mm
• Mounting position
  Any
• Actuation type
  Electrical
• Safety instructions
  MPYE safety position: if the power supply cable breaks, the blocked mid-position is approached.
• Operating pressure
  0 bar ... 10 bar
• Setpoint/actual values
  Voltage type 0 - 10 V
• Temperature of medium
  5 °C ... 40 °C
• Pneumatic connection 4
  G1/4
• Type code
  MPYE
• Reset method
  Magnetic spring
• Valve function
  5/3, closed
• Max. hysteresis
  0.4 %
• Cut-off frequency
  80 Hz
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Certification
  RCM compliance mark
• Pneumatic connection 2
  G¼
Cover material
ABS Coated
KC characters
KC EMC
Sealing principle
Hard
Type of control
Direct
C value
6.25 l/sbar
Operating medium
Compressed air as per ISO 8573-1:2010 [6:4:4]
Degree of protection
IP65
Electrical connection
4-pin Round design
Pneumatic connection 3
G1/4
Housing material
Aluminum Anodized
Reverse polarity protection
for all electrical connections
Standard nominal flow rate
1400 l/min
Residual ripple
5 %
Information on operating and pilot media
Operation with oil lubrication not possible
Ambient temperature
0 °C ... 50 °C
Type of mounting
With through-hole
Pneumatic connection 5
G1/4
Seals material
NBR
DC operating voltage range
17 V ... 30 V
CE marking (see declaration of conformity)
As per EU EMC directive
Product weight
510 g
Pneumatic connection 1
G1/4
Note on materials
RoHS-compliant
