151695 Festo Proportional Valves

151695 on Powermatic Associates
Festo

Part#:151695

Alt. Part#:MPYE-5-3/8-010-B

Manufacturer:Festo

Category:Proportional Valves

Product Lifecycle:Active

Product description

proportional directional control valve MPYE-5-3/8-010-B Nominal size: 10 mm, Type of actuation: electrical, Sealing principle: Hard, Assembly position: Any, Design structure: Piston slide

Product Details

  • Nominal width
    10 mm
  • Mounting position
    Any
  • Symbol
    00995308
  • Max. hysteresis
    0.4 %
  • Standard nominal flow rate
    2000 l/min
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Certification
    RCM compliance mark
  • Pneumatic connection 4
    G3/8
  • KC characters
    KC EMC
  • Sealing principle
    Hard
  • Reset method
    Magnetic spring
  • Valve function
    5/3, closed
  • C value
    9 l/sbar
  • DC operating voltage range
    17 V ... 30 V
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [6:4:4]
  • Ambient temperature
    0 °C ... 50 °C
  • Type of mounting
    With through-hole
  • Cover material
    ABS Coated
  • Housing material
    Aluminum Anodized
  • Type of control
    Direct
  • Reverse polarity protection
    for all electrical connections
  • Temperature of medium
    5 °C ... 40 °C
  • Pneumatic connection 1
    G3/8
  • Pneumatic connection 3
    G3/8
  • Note on materials
    RoHS-compliant
  • Actuation type
    Electrical
  • Safety instructions
    MPYE safety position: if the power supply cable breaks, the blocked mid-position is approached.
  • Operating pressure
    0 bar ... 10 bar
  • Cut-off frequency
    70 Hz
  • Information on operating and pilot media
    Operation with oil lubrication not possible
  • Degree of protection
    IP65
  • Product weight
    685 g
  • Pneumatic connection 2
    G3/8
  • Seals material
    NBR
  • Type code
    MPYE
  • Design
    Piston gate valve
  • Flow direction
    Non-reversible
  • b-value
    0.21
  • Residual ripple
    5 %
  • Setpoint/actual values
    Voltage type 0 - 10 V
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Electrical connection
    4-pin Round design
  • Pneumatic connection 5
    G3/8

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
