191986 Festo Proximity Sensors

191986 on Powermatic Associates
Festo

Part#:191986

Manufacturer:Festo

Category:Proximity Sensors

Alt. Part#:SMTSO-8E-PS-M12-LED-24

Product Lifecycle:Active

In-stock parts: 2

Dec 7, 2024

proximity sensor SMTSO-8E-PS-M12-LED-24 Electric, contactless, PNP, for drives with T-slot, without mounting kit, with M12 plug, welding field resistant design. Design: for T-slot, Authorisation: RCM Mark, CE mark (see declaration of conformity): to EU di

About the manufacturer: Festo is one of the manufacturers that offers Proximity Sensors that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 191986 Festo price in the box on the right side or send a quick quote.

Product Details

  • Electrical connection 1, type of mounting
    Screw-type lock
  • Repetition accuracy
    0.2 mm
  • Symbol
    00991153
  • Measuring principle
    Magneto-inductive
  • Switch-off time
    20 ms
  • Short-circuit protection
    yes
  • Connection outlet orientation
    Transverse
  • Degree of protection
    IP65 IP67
  • Design
    for T-slot
  • Special features
    Welding field resistant Resistant to welding spatter
  • Switching output
    PNP
  • Max. switching capacity DC
    6 W
  • Residual current
    ≤ 0.01 mA
  • Housing material
    Wrought aluminum alloy High-alloy stainless steel
  • Resistance to interference from magnetic fields
    45 - 65 Hz Alternating magnetic field
  • Electrical connection for input 1, connection pattern
    00995573
  • Note on materials
    Free of copper and PTFE
  • Switching element function
    N/O contact
  • Voltage drop
    ≤ 1.8 V
  • Reverse polarity protection
    for all electrical connections
  • Product weight
    19 g
  • Type code
    SMTSO
  • Electrical connection 1, connection type
    Plug
  • Certification
    RCM compliance mark
  • On time
    38 ms
  • Overload protection
    Available
  • Type of mounting
    With accessories
  • Electrical connection 1, connection technology
    M12x1 A-coded as per EN 61076-2-101
  • Electrical connection 1, number of pins/wires
    3
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Ambient temperature
    -25 °C ... 70 °C
  • Max. output current
    200 mA
  • DC operating voltage range
    10 V ... 30 V
  • Max. tightening torque plug
    0.5 Nm
  • Switching status indication
    LED yellow

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents 191986 Specs

191986 191986 DataSheet.pdf

This item can ship within 24h!

Manufacturer warranty

$235.08

Stock:

2

Select Qty:

$235.08

$235.08 each
