CS10.244
Puls
Product Lifecycle: Active
PULS CS10.244 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for an ambient air temperature range of 0 to +70°C. It has a net width of 60mm and dimensions of W60mm x H124mm x D117mm. This unit operates with a current consumption of 2.2A at 230Vac input for full 24Vdc output, with a peak inrush current of 59A at 230Vac input. It features an efficiency of 0.913 at 230Vac input. The CS10.244 has a start-up delay of 220ms and a rise time of 35ms to 75ms depending on the load capacitance. It includes protection functions such as output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. The unit supports series or parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 22.9W at full output load, with an output stage capacitance of 7000µF. Its electrical durability ranges from 64000 to 334000 hours, depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the C-Line series, offers a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage of 180Vac-264Vac, with a rated current of 12A at 24Vdc under 45°C and a rated power of 288W under the same temperature conditions. The output voltage is adjustable between 24Vdc and 28Vdc, featuring a 100mV turn-ON overshoot and a hold time of 45ms at 230Vac input.
![CS10.244](/_next/image?url=https%3A%2F%2Fappstoragepublicprod.s3.us-west-1.amazonaws.com%2FPartImage%2FCS10.244.jpg&w=3840&q=75)
PULS CS10.244 is a DIN rail mounting power supply unit encased in an aluminium housing, designed for an ambient air temperature range of 0 to +70°C. It has a net width of 60mm and dimensions of W60mm x H124mm x D117mm. This unit operates with a current consumption of 2.2A at 230Vac input for full 24Vdc output, with a peak inrush current of 59A at 230Vac input. It features an efficiency of 0.913 at 230Vac input. The CS10.244 has a start-up delay of 220ms and a rise time of 35ms to 75ms depending on the load capacitance. It includes protection functions such as output overvoltage protection, NTC for input inrush current limiting, and overload/short-circuit protection. The unit supports series or parallel operation for redundancy and is resistant to back-feeding loads up to 35V. Power dissipation/losses are 22.9W at full output load, with an output stage capacitance of 7000µF. Its electrical durability ranges from 64000 to 334000 hours, depending on the operating conditions. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit, part of the C-Line series, offers a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It accepts a supply voltage of 180Vac-264Vac, with a rated current of 12A at 24Vdc under 45°C and a rated power of 288W under the same temperature conditions. The output voltage is adjustable between 24Vdc and 28Vdc, featuring a 100mV turn-ON overshoot and a hold time of 45ms at 230Vac input.
Product details
- Efficiency91.3 %
- Current Output10 A
- Height124 mm
- Current Input2.2 A
- UL File No.E198865
- Width60 mm
- Phase1 Phase
- Power240 W
- Depth117 mm
