SDR-480-24 MEAN WELL AC/DC Power Supplies

SDR-480-24 on Powermatic Associates
MEAN WELL

Part#:SDR-480-24

Manufacturer:MEAN WELL

Category:AC/DC Power Supplies

Product Lifecycle:Active

Only 3 left in stock. Order Now!

Jun 30, 2025

Product description

AC-DC Industrial DIN rail power supply; Output 24Vdc at 20A; Metal casing; Ultra slim width 85.5mm

Product Details

  • Description
    AC-DC Industrial DIN rail power supply; Output 24Vdc at 20A; Metal casing; Ultra slim width 85.5mm
  • Application
    Installation UL 508 ITE EN/UL/IEC 60950
  • Input Voltage (V)
    110/230 universal input 90 - 264
  • Packing quantity
    8
  • Output Voltage (V)
    24
  • Depth (mm)
    128.5
  • Technology
    AC/DC
  • RoHS
    Compliant
  • Power Format
    DIN rail
  • Output Current (A)
    20
  • Width (mm)
    85.5
  • Series
    SDR-480
  • IP Rating
    No IP assigned
  • Net weight (gram)
    1640
  • Output Power (W)
    480
  • Height (mm)
    125.2
  • Item number
    SDR-480-24
  • Dimming Technology
    No Dimming

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
