S8VK-T48024 Omron AC/DC Power Supplies

Name: S8VK-T48024
Brand: Omron

Part#:S8VK-T48024

Manufacturer:Omron

Category:AC/DC Power Supplies

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Mar 13, 2025

Product description

Power supply: switched-mode; 480W; 24VDC; 20A; 450÷600VDC; DIN

Product Details

Country Of Origin
Indonesia
Standards
cULus, UL508, UL60950-1, cUL:CSA C22.2 No. 60950-1, EN/VDE: EN50178 (=VDE 0160), EN 60950-1 (=VDE 0805), ANSI/ISA 12.12.01 (Hazardous locations)
Under-voltage alarm
Yes
Cooling type
Natural (gravity)
Connection
Screw Terminal
Overload protection
Yes
Over-voltage protection
Yes
Enclosure type
Enclosed
Mounting
DIN Rail
Output voltage DC
24 V
Height range
125
Output current
20 A
Supply voltage, DC
450 to 810 VDC
Supply voltage AC 2-phase
340 to 576 VAC, 2-phase
Dimensions H x W x D mm
125 x 95 x 140
Output power
480 W
Width range
95
Depth range
140
Supply voltage, AC 3-phase
320 to 576 VAC, 3-phase

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

S8VK-T48024 Related Documents

Datasheet.pdf

Manufacturer warranty

S8VK-T48024 Omron

Get a quick Quote!

Request a quote, and we will send you price within minutes.

Stock:

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
