Name: PIM60.241
Brand: Puls

UF20.481

PULS UF20.481 is an Uninterruptible Power Supply (UPS) control module, part of the UF-series, designed as a bfr. module with capacitive storage and features a green status LED. It is housed in aluminium and utilizes spring-clamp connections for connectivity. This module measures W64mm x H124mm x D102mm and operates on a supply voltage range of 38.4Vdc to 60Vdc, with a nominal voltage of 48Vdc. It is rated for a current of 20A (bfr.) and is designed for DIN rail mounting. The UF20.481 can operate in ambient air temperatures ranging from -25 to +70°C and is suitable for DC networks. It includes a visual position indicator for Ready, Buffering, and Inhibit statuses. The module offers protection functions including output overvoltage protection, with typical protection at 58Vdc and a maximum of 60Vdc. Buffer modules can be connected in parallel to increase output ampacity or hold-up time. It provides a fixed output voltage of 48Vdc, boasts an efficiency of 0.99 at 48Vdc input, and offers a hold time of 15ms / 0.15s at a 20A load. Power dissipation/losses are 1.9 W at 24Vdc input with 0A output current. Ripple is specified as 250mVpp at 5A, 400mVpp at 10A, and 600mVpp at 20A, across a frequency range of 20Hz to 20MHz at 50Ω. Its electrical durability is rated at 161,000 hours at 40°C and 457,000 hours at 25°C in standby mode.

Puls

SL5.100

Verified stock: 1

PULS SL5.100 is a power supply unit designed with an EMC filter and DC-OK relay contact output. This AC/DC power supply unit (PSU) / converter is capable of a power boost up to 6A and features screw-clamp connections for secure installation. It has dimensions of W64mm x H124mm x D102mm and supports a wide range of supply voltages including AC: 85Vac-132Vac / 176Vac-264Vac and DC: 300Vdc, with a rated current of 5A at 24Vdc. The SL5.100 is designed for DIN rail mounting and can operate in ambient air temperatures ranging from 0 to +70°C. It has a net width of 64 mm and consumes 2.6A (with a 115V input) or 1.4A (with a 230V input), with a maximum inrush of 15A at 264Vac input. This unit is suitable for single-phase (1AC) or DC networks and includes protection functions against output overvoltage, short-circuit, and overload without switching off. The output voltage is fixed at 24Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 120W, with a hold time of 37ms at 196Vac input, and power dissipation/losses of 13.3W at full output load with a 230Vac input. It also features a 100ms start-up delay and a 5-20ms rise time under nominal input with a constant full current load, and a ripple of 50mVpp at 20Hz to 20MHz.

Puls

ML30.100

Verified stock: 2

PULS ML30.100 is a power supply unit designed for AC/DC conversion with a primary function to supply power. It supports DIN rail mounting for easy installation and operates within an ambient air temperature range of -10 to +70°C. This unit is designed according to NEC Class 2 standards, offering a rated current of 1.3A at 24Vdc, and utilizes spring-clamp connections for secure attachment. It accepts a wide range of supply voltages from 85Vac to 264Vac (covering standard voltages like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz, with a turn-ON voltage of 46Vac and a shutdown voltage of 44Vac) and also operates on DC supply voltages from 88Vdc to 375Vdc. The ML30.100 is housed in a PC/ABS blend, ensuring durability, and measures 45mm in width, 75mm in height, and 91mm in depth. It is compatible with single-phase (1AC) or DC networks, has a rated power of 30W, and provides an adjustable output voltage range of 24Vdc to 28Vdc with a 250mV turn-ON overshoot. The unit features protection functions including an NTC for input inrush current limiting, achieves an efficiency of 0.875 at 230Vac input, and has a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input. Power dissipation/losses are rated at 4.3W, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.

Puls

SL10.100

Verified stock: 1

PULS SL10.100 is a power supply unit featuring an EMC filter and DC-OK relay contact output. It operates as an AC/DC PSU/converter with capabilities for parallel operation and a power boost up to 288W. The unit is equipped with screw-clamp connections and has dimensions of W120mm x H124mm x D102mm. It supports a supply voltage range of 85Vac-132Vac / 176Vac-264Vac across various nominal voltages from 100Vac to 240Vac at a frequency of 47-63Hz. The SL10.100 provides a rated current of 10A at 24Vdc with a derating at 6W/+60°C to +70°C. Designed for DIN rail mounting, it can operate within an ambient air temperature range of 0 to +70 °C. The current consumption is 6A with a 115V input and 2.6A with a 230V input, with a maximum inrush of 30A at 264Vac input. This single-phase unit includes protection functions against output overvoltage (35V), short-circuit, overload/short-circuit current, and allows for series/parallel operation with power back immunity (34V). The output voltage is adjustable between 24Vdc and 28Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 288W at temperatures up to +45°C and 240W up to +60°C. It features a hold time of 25ms at 196Vac input, power dissipation/losses of 26.7W at full output load with 230Vac input, a start-up delay of 100ms, a rise time of 5-20ms under nominal input at constant full current load, and a ripple of 30mVpp at 20Hz to 20MHz with a 50Ω load.

Puls

ML60.121

Verified stock: 5

PULS ML60.121 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and adheres to NEC Class 2 design specifications. This unit provides a rated current of 4.5A at 12Vdc and features screw-clamp connections for secure installation. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values across 100Vac to 240Vac at 47-63Hz, including a 75Vac turn-ON voltage and a 65Vac shutdown voltage) and 88Vdc to 375Vdc (with nominal values from 100Vdc to 250Vdc), making it versatile for various electrical environments. The ML60.121 measures 45mm in width, 75mm in height, and 91mm in depth, housed in a PC / ABS blend for durability. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 54W and an adjustable output voltage range from 12Vdc to 15Vdc, with a 200mV turn-ON overshoot. Protection is provided by an NTC (input inrush current limiter), and the unit boasts an efficiency of 0.872 at 230Vac input, 0.853 at 120Vac input, and 0.835 at 100Vac input. Current consumption peaks at 16A max inrush (at 120Vac input) and 32A peak max inrush (at 230Vac input), with a 90-120ms start-up delay and a 40-50ms/90-110ms rise time under nominal input conditions. Power dissipation/losses are calculated at 7.9 W, with an electrical durability of 56,000 hours at +40°C. The output stage ripple is 50mVpp (20Hz to 20MHz; 50Ω), and the capacitance at the output stage is 3000µF.

Puls

PIM60.121

Verified stock: 0

PULS PIM60.121 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C, with linear derating up to +70°C, and features a NEC Class 2 DC-OK relay contact output. The unit provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C, utilizing screw-clamp connections. It supports a supply voltage range of 90Vac-264Vac across various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. The PIM-series part measures W36mm x H90mm x D91mm, has an IP20 protection degree, and is housed in polycarbonate. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable output voltage of 24Vdc-28Vdc. Protection functions include output overvoltage and overload/short-circuit protection, with specified current limits and conditions for back-feeding loads. The unit's efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively, with detailed current consumption, inrush peaks, time delay, hold time, power dissipation/losses, electrical durability, ripple, and capacitance specifications.

Puls

PIM60.245

Verified stock: 0

PULS PIM60.245 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The design includes a NEC Class 2 DC-OK relay contact output. It provides a rated current of 5A at 12Vdc from -10 to +60°C and 3.8A at 12Vdc at +70°C, utilizing screw-clamp connections. The supply voltage (AC) ranges from 90Vac to 264Vac for various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. Part of the PIM-series, it measures W36mm x H90mm x D91mm and has an IP20 degree of protection with a polycarbonate (PC) housing. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable DC output voltage of 12Vdc to 15Vdc. Protection functions include output overvoltage and overload/short-circuit current protection, with specific resistance and current values provided. The unit is resistant to back-feeding loads up to 16V. Efficiency rates are noted for 230Vac and 120Vac inputs, alongside current consumption details for various input voltages and inrush current peaks. Time delay for start-up and rise, hold time, power dissipation/losses, and electrical durability at different conditions and temperatures are specified. Ripple and capacitance values are also provided, highlighting the unit's electrical characteristics.

Puls

PIM60.125

Verified stock: 0

PULS PIM60.125 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. This unit features a NEC Class 2 DC-OK relay contact output and provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C. It offers push-in spring connections for ease of installation. The supply voltage (AC) ranges from 90Vac to 264Vac across various nominal voltages and frequencies, with specific input overvoltage and shutdown voltage parameters. The PIM-series unit measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in a polycarbonate (PC) material. Designed for single-phase (1AC) networks, it has a net width of 36 mm and delivers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 24Vdc and 28Vdc, with specific protection functions against overvoltage and overload/short-circuit conditions. It does not support series or parallel operation and is resistant to back-feeding loads. The efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively. Current consumption varies with input voltage, and the unit exhibits specific start-up delay, rise time, and hold time characteristics. Power dissipation/losses are detailed for different input conditions, and the electrical durability is specified across various operational conditions. The ripple is noted at 100mVpp, and the output stage capacitance is 900 µF.

Puls

UF20.481

Verified stock: 3

PULS UF20.481 is an Uninterruptible Power Supply (UPS) control module, part of the UF-series, designed as a bfr. module with capacitive storage and features a green status LED. It is housed in aluminium and utilizes spring-clamp connections for connectivity. This module measures W64mm x H124mm x D102mm and operates on a supply voltage range of 38.4Vdc to 60Vdc, with a nominal voltage of 48Vdc. It is rated for a current of 20A (bfr.) and is designed for DIN rail mounting. The UF20.481 can operate in ambient air temperatures ranging from -25 to +70°C and is suitable for DC networks. It includes a visual position indicator for Ready, Buffering, and Inhibit statuses. The module offers protection functions including output overvoltage protection, with typical protection at 58Vdc and a maximum of 60Vdc. Buffer modules can be connected in parallel to increase output ampacity or hold-up time. It provides a fixed output voltage of 48Vdc, boasts an efficiency of 0.99 at 48Vdc input, and offers a hold time of 15ms / 0.15s at a 20A load. Power dissipation/losses are 1.9 W at 24Vdc input with 0A output current. Ripple is specified as 250mVpp at 5A, 400mVpp at 10A, and 600mVpp at 20A, across a frequency range of 20Hz to 20MHz at 50Ω. Its electrical durability is rated at 161,000 hours at 40°C and 457,000 hours at 25°C in standby mode.

Puls

SL5.100

Verified stock: 1

PULS SL5.100 is a power supply unit designed with an EMC filter and DC-OK relay contact output. This AC/DC power supply unit (PSU) / converter is capable of a power boost up to 6A and features screw-clamp connections for secure installation. It has dimensions of W64mm x H124mm x D102mm and supports a wide range of supply voltages including AC: 85Vac-132Vac / 176Vac-264Vac and DC: 300Vdc, with a rated current of 5A at 24Vdc. The SL5.100 is designed for DIN rail mounting and can operate in ambient air temperatures ranging from 0 to +70°C. It has a net width of 64 mm and consumes 2.6A (with a 115V input) or 1.4A (with a 230V input), with a maximum inrush of 15A at 264Vac input. This unit is suitable for single-phase (1AC) or DC networks and includes protection functions against output overvoltage, short-circuit, and overload without switching off. The output voltage is fixed at 24Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 120W, with a hold time of 37ms at 196Vac input, and power dissipation/losses of 13.3W at full output load with a 230Vac input. It also features a 100ms start-up delay and a 5-20ms rise time under nominal input with a constant full current load, and a ripple of 50mVpp at 20Hz to 20MHz.

Puls

ML30.100

Verified stock: 2

PULS ML30.100 is a power supply unit designed for AC/DC conversion with a primary function to supply power. It supports DIN rail mounting for easy installation and operates within an ambient air temperature range of -10 to +70°C. This unit is designed according to NEC Class 2 standards, offering a rated current of 1.3A at 24Vdc, and utilizes spring-clamp connections for secure attachment. It accepts a wide range of supply voltages from 85Vac to 264Vac (covering standard voltages like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz, with a turn-ON voltage of 46Vac and a shutdown voltage of 44Vac) and also operates on DC supply voltages from 88Vdc to 375Vdc. The ML30.100 is housed in a PC/ABS blend, ensuring durability, and measures 45mm in width, 75mm in height, and 91mm in depth. It is compatible with single-phase (1AC) or DC networks, has a rated power of 30W, and provides an adjustable output voltage range of 24Vdc to 28Vdc with a 250mV turn-ON overshoot. The unit features protection functions including an NTC for input inrush current limiting, achieves an efficiency of 0.875 at 230Vac input, and has a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input. Power dissipation/losses are rated at 4.3W, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.

Puls

SL10.100

Verified stock: 1

PULS SL10.100 is a power supply unit featuring an EMC filter and DC-OK relay contact output. It operates as an AC/DC PSU/converter with capabilities for parallel operation and a power boost up to 288W. The unit is equipped with screw-clamp connections and has dimensions of W120mm x H124mm x D102mm. It supports a supply voltage range of 85Vac-132Vac / 176Vac-264Vac across various nominal voltages from 100Vac to 240Vac at a frequency of 47-63Hz. The SL10.100 provides a rated current of 10A at 24Vdc with a derating at 6W/+60°C to +70°C. Designed for DIN rail mounting, it can operate within an ambient air temperature range of 0 to +70 °C. The current consumption is 6A with a 115V input and 2.6A with a 230V input, with a maximum inrush of 30A at 264Vac input. This single-phase unit includes protection functions against output overvoltage (35V), short-circuit, overload/short-circuit current, and allows for series/parallel operation with power back immunity (34V). The output voltage is adjustable between 24Vdc and 28Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 288W at temperatures up to +45°C and 240W up to +60°C. It features a hold time of 25ms at 196Vac input, power dissipation/losses of 26.7W at full output load with 230Vac input, a start-up delay of 100ms, a rise time of 5-20ms under nominal input at constant full current load, and a ripple of 30mVpp at 20Hz to 20MHz with a 50Ω load.

Puls

ML60.121

Verified stock: 5

PULS ML60.121 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and adheres to NEC Class 2 design specifications. This unit provides a rated current of 4.5A at 12Vdc and features screw-clamp connections for secure installation. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values across 100Vac to 240Vac at 47-63Hz, including a 75Vac turn-ON voltage and a 65Vac shutdown voltage) and 88Vdc to 375Vdc (with nominal values from 100Vdc to 250Vdc), making it versatile for various electrical environments. The ML60.121 measures 45mm in width, 75mm in height, and 91mm in depth, housed in a PC / ABS blend for durability. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 54W and an adjustable output voltage range from 12Vdc to 15Vdc, with a 200mV turn-ON overshoot. Protection is provided by an NTC (input inrush current limiter), and the unit boasts an efficiency of 0.872 at 230Vac input, 0.853 at 120Vac input, and 0.835 at 100Vac input. Current consumption peaks at 16A max inrush (at 120Vac input) and 32A peak max inrush (at 230Vac input), with a 90-120ms start-up delay and a 40-50ms/90-110ms rise time under nominal input conditions. Power dissipation/losses are calculated at 7.9 W, with an electrical durability of 56,000 hours at +40°C. The output stage ripple is 50mVpp (20Hz to 20MHz; 50Ω), and the capacitance at the output stage is 3000µF.

Puls

PIM60.121

Verified stock: 0

PULS PIM60.121 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C, with linear derating up to +70°C, and features a NEC Class 2 DC-OK relay contact output. The unit provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C, utilizing screw-clamp connections. It supports a supply voltage range of 90Vac-264Vac across various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. The PIM-series part measures W36mm x H90mm x D91mm, has an IP20 protection degree, and is housed in polycarbonate. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable output voltage of 24Vdc-28Vdc. Protection functions include output overvoltage and overload/short-circuit protection, with specified current limits and conditions for back-feeding loads. The unit's efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively, with detailed current consumption, inrush peaks, time delay, hold time, power dissipation/losses, electrical durability, ripple, and capacitance specifications.

Puls

PIM60.245

Verified stock: 0

PULS PIM60.245 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. The design includes a NEC Class 2 DC-OK relay contact output. It provides a rated current of 5A at 12Vdc from -10 to +60°C and 3.8A at 12Vdc at +70°C, utilizing screw-clamp connections. The supply voltage (AC) ranges from 90Vac to 264Vac for various nominal voltages and frequencies, with specific input overvoltage and turn-on/shutdown voltages detailed. Part of the PIM-series, it measures W36mm x H90mm x D91mm and has an IP20 degree of protection with a polycarbonate (PC) housing. Designed for single-phase networks, it offers a rated power of 60W at -10 to +60°C and 45.6W at +70°C, with an adjustable DC output voltage of 12Vdc to 15Vdc. Protection functions include output overvoltage and overload/short-circuit current protection, with specific resistance and current values provided. The unit is resistant to back-feeding loads up to 16V. Efficiency rates are noted for 230Vac and 120Vac inputs, alongside current consumption details for various input voltages and inrush current peaks. Time delay for start-up and rise, hold time, power dissipation/losses, and electrical durability at different conditions and temperatures are specified. Ripple and capacitance values are also provided, highlighting the unit's electrical characteristics.

Puls

PIM60.125

Verified stock: 0

PULS PIM60.125 is a power supply unit that functions as an AC/DC PSU/converter with DIN rail mounting. It operates within an ambient air temperature range of -10 to +60°C with linear derating up to +70°C. This unit features a NEC Class 2 DC-OK relay contact output and provides a rated current of 2.5A at 24Vdc within -10 to +60°C and 1.9A at 24Vdc at +70°C. It offers push-in spring connections for ease of installation. The supply voltage (AC) ranges from 90Vac to 264Vac across various nominal voltages and frequencies, with specific input overvoltage and shutdown voltage parameters. The PIM-series unit measures W36mm x H90mm x D91mm, has an IP20 degree of protection, and is housed in a polycarbonate (PC) material. Designed for single-phase (1AC) networks, it has a net width of 36 mm and delivers a rated power of 60W at -10 to +60°C, which derates linearly to 45.6W at +70°C. The output voltage (DC) is adjustable between 24Vdc and 28Vdc, with specific protection functions against overvoltage and overload/short-circuit conditions. It does not support series or parallel operation and is resistant to back-feeding loads. The efficiency rates are 0.918 and 0.907 for 230Vac and 120Vac inputs, respectively. Current consumption varies with input voltage, and the unit exhibits specific start-up delay, rise time, and hold time characteristics. Power dissipation/losses are detailed for different input conditions, and the electrical durability is specified across various operational conditions. The ripple is noted at 100mVpp, and the output stage capacitance is 900 µF.

Puls

UF20.481

Verified stock: 3

PULS UF20.481 is an Uninterruptible Power Supply (UPS) control module, part of the UF-series, designed as a bfr. module with capacitive storage and features a green status LED. It is housed in aluminium and utilizes spring-clamp connections for connectivity. This module measures W64mm x H124mm x D102mm and operates on a supply voltage range of 38.4Vdc to 60Vdc, with a nominal voltage of 48Vdc. It is rated for a current of 20A (bfr.) and is designed for DIN rail mounting. The UF20.481 can operate in ambient air temperatures ranging from -25 to +70°C and is suitable for DC networks. It includes a visual position indicator for Ready, Buffering, and Inhibit statuses. The module offers protection functions including output overvoltage protection, with typical protection at 58Vdc and a maximum of 60Vdc. Buffer modules can be connected in parallel to increase output ampacity or hold-up time. It provides a fixed output voltage of 48Vdc, boasts an efficiency of 0.99 at 48Vdc input, and offers a hold time of 15ms / 0.15s at a 20A load. Power dissipation/losses are 1.9 W at 24Vdc input with 0A output current. Ripple is specified as 250mVpp at 5A, 400mVpp at 10A, and 600mVpp at 20A, across a frequency range of 20Hz to 20MHz at 50Ω. Its electrical durability is rated at 161,000 hours at 40°C and 457,000 hours at 25°C in standby mode.

Puls

SL5.100

Verified stock: 1

PULS SL5.100 is a power supply unit designed with an EMC filter and DC-OK relay contact output. This AC/DC power supply unit (PSU) / converter is capable of a power boost up to 6A and features screw-clamp connections for secure installation. It has dimensions of W64mm x H124mm x D102mm and supports a wide range of supply voltages including AC: 85Vac-132Vac / 176Vac-264Vac and DC: 300Vdc, with a rated current of 5A at 24Vdc. The SL5.100 is designed for DIN rail mounting and can operate in ambient air temperatures ranging from 0 to +70°C. It has a net width of 64 mm and consumes 2.6A (with a 115V input) or 1.4A (with a 230V input), with a maximum inrush of 15A at 264Vac input. This unit is suitable for single-phase (1AC) or DC networks and includes protection functions against output overvoltage, short-circuit, and overload without switching off. The output voltage is fixed at 24Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 120W, with a hold time of 37ms at 196Vac input, and power dissipation/losses of 13.3W at full output load with a 230Vac input. It also features a 100ms start-up delay and a 5-20ms rise time under nominal input with a constant full current load, and a ripple of 50mVpp at 20Hz to 20MHz.

Puls

ML30.100

Verified stock: 2

PULS ML30.100 is a power supply unit designed for AC/DC conversion with a primary function to supply power. It supports DIN rail mounting for easy installation and operates within an ambient air temperature range of -10 to +70°C. This unit is designed according to NEC Class 2 standards, offering a rated current of 1.3A at 24Vdc, and utilizes spring-clamp connections for secure attachment. It accepts a wide range of supply voltages from 85Vac to 264Vac (covering standard voltages like 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac at 47-63Hz, with a turn-ON voltage of 46Vac and a shutdown voltage of 44Vac) and also operates on DC supply voltages from 88Vdc to 375Vdc. The ML30.100 is housed in a PC/ABS blend, ensuring durability, and measures 45mm in width, 75mm in height, and 91mm in depth. It is compatible with single-phase (1AC) or DC networks, has a rated power of 30W, and provides an adjustable output voltage range of 24Vdc to 28Vdc with a 250mV turn-ON overshoot. The unit features protection functions including an NTC for input inrush current limiting, achieves an efficiency of 0.875 at 230Vac input, and has a maximum inrush current consumption of 17A at 120Vac input and 35A peak at 230Vac input. Power dissipation/losses are rated at 4.3W, and it maintains a ripple of 50mVpp across a frequency range of 20Hz to 20MHz at 50Ω.

Puls

SL10.100

Verified stock: 1

PULS SL10.100 is a power supply unit featuring an EMC filter and DC-OK relay contact output. It operates as an AC/DC PSU/converter with capabilities for parallel operation and a power boost up to 288W. The unit is equipped with screw-clamp connections and has dimensions of W120mm x H124mm x D102mm. It supports a supply voltage range of 85Vac-132Vac / 176Vac-264Vac across various nominal voltages from 100Vac to 240Vac at a frequency of 47-63Hz. The SL10.100 provides a rated current of 10A at 24Vdc with a derating at 6W/+60°C to +70°C. Designed for DIN rail mounting, it can operate within an ambient air temperature range of 0 to +70 °C. The current consumption is 6A with a 115V input and 2.6A with a 230V input, with a maximum inrush of 30A at 264Vac input. This single-phase unit includes protection functions against output overvoltage (35V), short-circuit, overload/short-circuit current, and allows for series/parallel operation with power back immunity (34V). The output voltage is adjustable between 24Vdc and 28Vdc, with an efficiency of 0.9 at 230Vac input. The rated power is 288W at temperatures up to +45°C and 240W up to +60°C. It features a hold time of 25ms at 196Vac input, power dissipation/losses of 26.7W at full output load with 230Vac input, a start-up delay of 100ms, a rise time of 5-20ms under nominal input at constant full current load, and a ripple of 30mVpp at 20Hz to 20MHz with a 50Ω load.

Puls

ML60.121

Verified stock: 5

PULS ML60.121 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and adheres to NEC Class 2 design specifications. This unit provides a rated current of 4.5A at 12Vdc and features screw-clamp connections for secure installation. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values across 100Vac to 240Vac at 47-63Hz, including a 75Vac turn-ON voltage and a 65Vac shutdown voltage) and 88Vdc to 375Vdc (with nominal values from 100Vdc to 250Vdc), making it versatile for various electrical environments. The ML60.121 measures 45mm in width, 75mm in height, and 91mm in depth, housed in a PC / ABS blend for durability. It is compatible with single-phase (1AC) or DC networks, offering a rated power of 54W and an adjustable output voltage range from 12Vdc to 15Vdc, with a 200mV turn-ON overshoot. Protection is provided by an NTC (input inrush current limiter), and the unit boasts an efficiency of 0.872 at 230Vac input, 0.853 at 120Vac input, and 0.835 at 100Vac input. Current consumption peaks at 16A max inrush (at 120Vac input) and 32A peak max inrush (at 230Vac input), with a 90-120ms start-up delay and a 40-50ms/90-110ms rise time under nominal input conditions. Power dissipation/losses are calculated at 7.9 W, with an electrical durability of 56,000 hours at +40°C. The output stage ripple is 50mVpp (20Hz to 20MHz; 50Ω), and the capacitance at the output stage is 3000µF.

Puls
