VS3AN5XLPQ Banner Proximity Sensors

VS3AN5XLPQ on Powermatic Associates
Banner

Part#:VS3AN5XLPQ

Alt. Part#:62620

Manufacturer:Banner

Category:Proximity Sensors

Product Lifecycle:Active

Product description

VS3 Series: Polarized Retro; Range: 250 mm; Input: 10-30 V dc; Output: NPN Light Operate; 3-pin M8 QD

Product Details

  • Weight
    36.28736 g
  • Country Of Origin
    MX
  • Feature: Audible
    No
  • Feature: Chemical Resistant
    No
  • Feature: Hazardous Area
    No
  • Feature: Encapsulated
    No
  • Opposed Mode Emitter/Receiver
    N/A
  • DeviceNet
    No
  • Feature: Timing (Hold/Delay)
    No
  • IO Link
    No
  • Barrel Diameter (mm)
    N/A
  • Adjustments
    N/A
  • Lens Material
    Glass
  • Indicator
    LEDs
  • Max Op. Relative Humidity [%]
    80% @ 50°C
  • NEMA Rating
    NEMA 6
  • IP Rating
    IP67
  • Number of Pins
    3
  • Repeatability (µs)
    160
  • Delay at Power-up (ms)
    150
  • Special Feature: Water Detection
    No
  • Special Feature: Intrinsically Safe
    No
  • Special Feature: Remote Teach
    No
  • Quick Disconnect Type
    M8 (Pico)
  • Operation
    Light Operate
  • Min Op. Temp. (°C)
    -20
  • Connection
    Pigtail QD
  • Output response time (ms)
    1
  • Max Op. Temp. (°C)
    55
  • Sensing Mode (Detailed)
    Polarized (Coaxial)
  • Max Sensing Distance (mm)
    250
  • Primary Housing Material
    Thermoplastic
  • Power
    DC
  • Housing Style
    Rectangular
  • Power Supply/Supply Voltage
    10-30 V dc
  • Input/Output
    Discrete
  • Outputs
    NPN
  • Sensing Mode (General)
    Retroreflective
  • Sensing Beam
    Visible Red LED

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of VS3AN5XLPQ on Powermatic Associates is $140.00. Order now.

About the product

Banner Engineering VS3AN5XLPQ is a polarized (coaxial) photo-electric sensor designed for retro-reflective operation. This sensor is housed in thermoplastic with a glass lens and an acrylic lid cover, ensuring durability. It operates within an ambient air temperature range of -20 to +55°C and offers a sensing distance of 250mm. The VS3AN5XLPQ features a visible red light with a wavelength of 680 nm and operates in Light-ON NO (Normally Open) mode. It is equipped with a single digital output (NPN transistor) and boasts a rapid response time of 1ms / 0.001 s. For connectivity, it comes pre-equipped with a 3-pin Pico-style M8 connector. This rectangular-shaped sensor is designed to meet IP67 and NEMA 6 protection standards, making it suitable for challenging environments. It requires a supply voltage of 10Vdc-30Vdc (12Vdc / 24Vdc nom.) and is part of the VS3 series.
