574341 Festo Proximity Sensors

Product Details

• Type code
  SMT
• Electrical connection 1, connection technology
  Open end
• Electrical connection 1, number of pins/wires
  2
• Repetition accuracy
  0.2 mm
• ATEX category for dust
  II 3D
• Special features
  Oil-resistant
• Switching output
  Non-contact, 2-wire
• Max. output current in mounting kits
  50 mA
• Max. switching capacity DC in mounting kits
  1.2 W
• DC operating voltage range
  7 V ... 30 V
• Color cable sheath
  Gray
• Housing colour
  Black
• Degree of protection
  IP65 IP69K
• Electrical connection 1, connection type
  Cable
• Design
  for T-slot
• Based on norm
  EN 60947-5-2
• Explosion prevention and protection
  Zone 2 (ATEX) Zone 22 (ATEX)
• Type of (ignition) protection for dust
  Ex tc IIIC T120°C X Dc
• Ambient temperature
  -40 °C ... 85 °C
• Max. output current
  80 mA
Overload protection
Available
Rated operating voltage DC
24 V
Type of mounting
Screwed tightly Can be inserted in slot from above
Switching status indication
LED yellow
KC characters
KC EMC
Symbol
00991623
ATEX category gas
II 3G
Note on materials
Free of copper and PTFE Halogen-free
Switch-off time
≤ 1 ms
Max. switching frequency
180 Hz
Connector cable test conditions
Flexural strength: as per Festo standard Torsional resistance: > 300 000 cycles, ±270°/0.1 m
Material of cable sheath
TPE-U(PUR)
Ambient temperature with flexible cable installation
-20 °C ... 85 °C
CE marking (see declaration of conformity)
As per EU EMC directive As per EU RoHS directive
Type of ignition protection for gas
Ex nA IIC T4 X Gc
Explosive ambient temperature
-40°C <= Ta <= +70°C
Switching element function
N/O contact
On time
≤ 1 ms
Voltage drop
< 6 V
Connection outlet orientation
Longitudinal
Cable characteristic
Suitability for energy chains/robot applications
Max. tightening torque
0.6 Nm
Product weight
57.1 g
Certification
RCM compliance mark c UL us - Listed (OL)
Measuring principle
Magneto-resistive
Measured variable
Position
Max. switching capacity DC
1.9 W
Short-circuit protection
yes
Reverse polarity protection
for all electrical connections
Cable length
5 m
Mounting position
Any
Housing material
PA-reinforced High-alloy stainless steel
Function reserve indication
LED orange
