5242202 Festo Servo Motors

Name: 5242202
Brand: Festo

Part#:5242202

Manufacturer:Festo

Alt. Part#:EMMT-AS-60-S-HS-RSB

Product Lifecycle:Active

Get a quick Quote!

servo motor EMMT-AS-60-S-HS-RSB Ambient temperature: -15 - 40 °C, Note on ambient temperature: up to 80°C with derating -1.5%/°C, Max. installation height: 4000 m, Note on max. installation height: As of 1,000 m, only with derating of -1.0% per 100 m, Sto

About the manufacturer: Festo is one of the manufacturers that offers Servo Motors that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 5242202 Festo price in the box on the right side or send a quick quote.

Product Details

Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Note on ambient temperature
Up to 80 °C with derating of -1.5% per degree Celsius
Certificate issuing authority
UL E342973
Max. brake no-load speed
10000 1/min
Brake current consumption
0.46 A
Number of pole pairs
5
Cross inductivity Lq (phase)
15.5 mH
Rotor position encoder system accuracy angle measurement
-120 arcsec ... 120 arcsec
Rotor position sensor
Absolute encoder, single-turn
Nominal rotary speed
3000 1/min
Nominal operating voltage DC
565 V
Winding inductance phase-phase
21 mH
Storage temperature
-20 °C ... 70 °C
Ambient temperature
-15 °C ... 40 °C
Nominal torque
0.6 Nm
MTTF, subcomponent
190 years, rotor position sensor
Interface code, motor out
60P
Electrical connection 1, connection technology
M23x1
Concentricity, coaxiality, axial runout according to DIN SPEC 42955
N
Information on max. installation height
with 1,000 m and longer only with derating of -1.0% per 100 m

Measuring flange

250 x 250 x 15 mm, steel

Max. winding temperature

155 °C

Max. installation height

4000 m

Max. mechanical speed

16000 1/min

Max. brake friction work

5600 J

Winding longitudinal inductivity Ld (phase)

13 mH

Thermal resistance

1.5 K/W

Rotor position sensor interface

EnDat® 22

Brake power consumption

11 W

Motor nominal power

190 W

Peak current

5.4 A

Corrosion resistance class (CRC)

0 - No corrosion stress

Brake mass moment of inertia

0.074 kgcm²

Permissible axial shaft load

70 N

Product weight

1500 g

Conforms to standard

IEC 60034

Electrical connection for input 1, connection pattern

00995913

Mounting position

Any

Contamination level

Balancing quality

G 2.5

Brake airflow

0.33 A

Brake coil resistance

52.4 Ohm

Storage lifetime, under nominal conditions

20000 h

DC brake response delay

≤ 2 ms

Rotor position encoder for absolutely detectable revolutions

Rotor position encoder for positional values per revolution

262144

Temperature monitoring

Digital motor temperature transmission via EnDat® 2.2

Continuous stall current

1.6 A

Phase-phase winding resistance

11.7 Ohm

CE marking (see declaration of conformity)

As per EU EMC directive As per EU RoHS directive

Thermal class according to EN 60034-1

Total output inertia moment

0.257 kgcm²

Stall torque

0.66 Nm

MTTFd, subcomponent

380 years, rotor position sensor

Electrical connection 1, connection type

Hybrid plug

Electrical connection 1, number of pins/wires

Brake coil inductivity

700 mH

Brake closing time

10 ms

Brake separation time

≤ 35 ms

Rotor position encoder for DC operating voltage range

3.6 V ... 14 V

Type code

EMMT-AS

Rotor position sensor measuring principle

Inductive

Brake DC operating voltage

24 V

Motor nominal current

1.4 A

Type of winding switch

Star inside

Rating class according to EN 60034-1

Degree of protection

IP40

Brake holding torque

2.5 Nm

Permissible radial shaft load

350 N

Detent torque

< 1.0% of peak torque

Rotor position sensor for manufacturer designation

ECI 1118

Note on degree of protection

IP40 for motor shaft without rotary shaft seal IP67 for motor housing, incl. connection technology

Vibration resistance

Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6

Motor type as per EN 60034-7

IM B5 IM V3

Rotor position encoder for DC operating voltage

5 V

Brake stopping current

0.33 A

Electric time constant

2.1 ms

Standstill torque constant

0.49 Nm/A

Thermal time constant

41 min

Max. rotational speed

12500 1/min

Motor constants

0.41 Nm/A

Rotor position sensor resolution

18 bit

Voltage constant, phase-to-phase

29.9 mVmin

Relative air humidity

0 - 90 %

Certification

RCM compliance mark c UL us - Recognized (OL)

Peak torque

1.6 Nm

Switching cycles, holding brake

10 million idle actuations (without friction work!)

Note on materials

Contains paint-wetting impairment substances RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
