5242216 Festo Servo Motors

Product Details

• Electrical connection 1, connection technology
  M23x1
• Electrical connection for input 1, connection pattern
  00995913
• Shock resistance
  Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
• Rotor position sensor resolution
  18 bit
• Detent torque
  < 1.0% of peak torque
• Note on degree of protection
  IP40 for motor shaft without rotary shaft seal IP67 for motor housing, incl. connection technology
• Note on ambient temperature
  Up to 80 °C with derating of -1.5% per degree Celsius
• Max. winding temperature
  155 °C
• Max. installation height
  4000 m
• Cross inductivity Lq (phase)
  5 mH
• Rotor position encoder system accuracy angle measurement
  -120 arcsec ... 120 arcsec
• Rotor position sensor
  Absolute encoder, single-turn
• Rotor position sensor measuring principle
  Inductive
• Electrical connection 1, connection type
  Hybrid plug
• Concentricity, coaxiality, axial runout according to DIN SPEC 42955
  N
• Rotor position sensor for manufacturer designation
  ECI 1118
• Contamination level
  2
• Motor type as per EN 60034-7
  IM B5 IM V3
• Rotor position encoder for DC operating voltage
  5 V
• Winding longitudinal inductivity Ld (phase)
  4.2 mH
Thermal time constant
43 min
Type code
EMMT-AS
Continuous stall current
3.8 A
Phase-phase winding resistance
2.68 Ohm
CE marking (see declaration of conformity)
As per EU EMC directive As per EU RoHS directive
Storage temperature
-20 °C ... 70 °C
Certification
RCM compliance mark c UL us - Recognized (OL)
Permissible radial shaft load
350 N
Mounting position
Any
Information on max. installation height
with 1,000 m and longer only with derating of -1.0% per 100 m
Electrical connection 1, number of pins/wires
15
Max. mechanical speed
16000 1/min
Rotor position encoder for DC operating voltage range
3.6 V ... 14 V
Rotor position sensor interface
EnDat® 22
Nominal rotary speed
3000 1/min
Motor nominal current
3.2 A
Type of winding switch
Star inside
Peak current
18.3 A
Total output inertia moment
0.403 kgcm²
Permissible axial shaft load
70 N
Product weight
1910 g
Conforms to standard
IEC 60034
Measuring flange
250 x 250 x 15 mm, steel
Certificate issuing authority
UL E342973
Number of pole pairs
5
Electric time constant
3 ms
Rotor position encoder for absolutely detectable revolutions
1
Rotor position encoder for positional values per revolution
262144
Max. rotational speed
11900 1/min
Motor constants
0.44 Nm/A
Motor nominal power
440 W
Corrosion resistance class (CRC)
0 - No corrosion stress
Relative air humidity
0 - 90 %
Nominal torque
1.4 Nm
MTTFd, subcomponent
380 years, rotor position sensor
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Balancing quality
G 2.5
Storage lifetime, under nominal conditions
20000 h
Standstill torque constant
0.52 Nm/A
Thermal resistance
1 K/W
Temperature monitoring
Digital motor temperature transmission via EnDat® 2.2
Nominal operating voltage DC
565 V
Winding inductance phase-phase
7 mH
Rating class according to EN 60034-1
S1
Degree of protection
IP40
Thermal class according to EN 60034-1
F
Interface code, motor out
60P
Voltage constant, phase-to-phase
31.2 mVmin
Ambient temperature
-15 °C ... 40 °C
Stall torque
1.66 Nm
Peak torque
5.6 Nm
Note on materials
Contains paint-wetting impairment substances RoHS-compliant
MTTF, subcomponent
190 years, rotor position sensor
