159706 Festo Directional Control Valves

159706 on Powermatic Associates
Festo

Part#:159706

Alt. Part#:MN1H-5/3E-D-3-S-C

Manufacturer:Festo

Category:Directional Control Valves

Product Lifecycle:Active

Product description

solenoid valve MN1H-5/3E-D-3-S-C With manual override, without solenoid coil or socket. Solenoid coil and socket should be ordered separately. Valve function: 5/3 exhausted, Type of actuation: electrical, Width: 65 mm, Standard nominal flow rate: 4600 l/m

Product Details

  • Actuation type
    Electrical
  • Standard nominal flow rate
    4600 l/min
  • Design
    Piston gate valve
  • ISO code
    369
  • Pilot pressure
    3 bar ... 10 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Vibration resistance
    Transport application test with severity level 1 as per FN 942017-4 and EN 60068-2-6
  • Electrical connection
    Via N1 coil, to be ordered separately
  • Pilot exhaust air port 84
    M5
  • Pneumatic connection 4
    Sub-base, size 3 as per ISO 5599-1
  • Lap
    Overlap
  • Pneumatic working port
    Sub-base, size 3 as per ISO 5599-1 G1/2
  • Operating voltage
    Via solenoid coil, to be ordered separately
  • Type code
    MN1H
  • Manual override
    Detenting via accessory Non-detenting
  • Switching time off
    84 ms
  • On switching time
    36 ms
  • Product weight
    1170 g
  • Pilot exhaust air port 82
    M5
  • Pilot air port 14
    Sub-base, size 3 as per ISO 5599-1
  • Pneumatic connection 5
    Sub-base, size 3 as per ISO 5599-1
  • Reset method
    Mechanical spring
  • Exhaust air function
    With flow control option
  • Mounting position
    Any
  • Type of control
    Pilot-controlled
  • Max. positive test pulse with 0 signal
    3700 µs
  • Shock resistance
    Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
  • Noise level
    85 dB(A)
  • Pneumatic connection 1
    Sub-base, size 3 as per ISO 5599-1
  • Pneumatic connection 3
    Sub-base, size 3 as per ISO 5599-1
  • Housing material
    Die-cast aluminum
  • Valve function
    5/3, exhausted
  • Width
    65 mm
  • Degree of protection
    IP65
  • Sealing principle
    Soft
  • Conforms to standard
    ISO 5599-1
  • Pilot air supply port
    External
  • Max. negative test pulse on 1 signal
    4600 µs
  • Temperature of medium
    -5 °C ... 50 °C
  • Pilot medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Pilot air port 12
    Sub-base, size 3 as per ISO 5599-1
  • Seals material
    HNBR NBR
  • Maritime classification
    See certificate
  • Operating pressure
    -0.9 bar ... 16 bar
  • Nominal width
    14.5 mm
  • Width dimension
    71 mm
  • Flow direction
    Reversible
  • Symbol
    00991077
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Ambient temperature
    -5 °C ... 50 °C
  • Type of mounting
    On sub-base With through-hole and screw
  • Pneumatic connection 2
    Sub-base, size 3 as per ISO 5599-1
  • Note on materials
    RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
