LS2HDTR30-600Q8 Banner Safety Light Curtains

Name: LS2HDTR30-600Q8
Brand: Banner
Price: 966 USD
Availability: BackOrder

LS2HDTR30-600Q8 on Powermatic Associates

Part#:LS2HDTR30-600Q8

Alt. Part#:80878

Manufacturer:Banner

Category:Safety Light Curtains

Product Lifecycle:Active

Product description

LS2HDTR30-600Q8 EZS T2 HD RCVR TRIP 30 mm x 600 mm TYPE2 HEAVY DUTY

Product Details

Weight
1814.368 g
Country Of Origin
CN
Safety Level
Type 2
Operating Voltage
24 V dc +/- 20%
Shock
10g at 16ms (6000 cycles)
Test Input
Yes
Operating Distance (m)
0.2 - 15
Dimensions WxD (mm)
33.7 x 34.8
Electrical Safety Class
III
Supply Current
90 mA max.
External Monitoring Device
No
Recovery Time
N/A
System Type
Receiver
Auxiliary Output
No
Feature: End-to-End Sensing
No
Primary Housing Material
Aluminum
IP Rating
IP65
Response Time
16
Fault Output
No
Feature: Integral Muting
No

low-profile

Housing Finish

Yellow Polyester

SIL Rating

SIL2; CL2

Vibration

10-55 Hz at 0.35 mm

Connector Type

M12

Fixed Blanking

Reduced Resolution

OSSD Rating

24 V dc at 0.5 A each

Overall Length (mm)

665

Operating Temperature

0 to +55 deg. C; RH 95%

Resolution (mm)

Housing Material

Aluminum; Zinc; Acrylic

Effective Aperture Angle

Type 2 Per IEC 61496-2

Number of Pins (Receiver/Emitter)

Scan Code

None

Trip/Latch Output

Trip

Defined Area Height (mm)

600

PL Rating

N/A

Short Protection

Yes

Feature: ESD Safe

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LS2HDTR30-600Q8 on Powermatic Associates is $966.00. Order now.

About the product

Banner Engineering LS2HDTR30-600Q8 is a safety light curtain designed for hand detection with a protective height of 600mm and a resolution of 30mm. This part of the LS2HD series type 2 light screens functions as a safety light screen/curtain receiver alone, featuring a trip output heavy-duty design. It has a yellow aluminum housing with an acrylic lens and die-cast zinc end caps. The device offers a beam spacing/pitch of 30mm and is pre-equipped with an 8-pin Euro-style M12 connector for connectivity. It operates on a 24Vdc supply voltage, with a net height of 665mm, a width of 34mm, and a depth of 35mm. The LS2HDTR30-600Q8 operates within an ambient air temperature range of 0 to +55°C and offers a degree of protection rated at IP65. It has a sensing distance ranging from 20cm to 15m and includes 2 x digital outputs (24Vdc; 500mA; sourcing; redundant OSSD solid-state outputs) with a response time of 16ms / 0.016 s.
