Name: 3044636
Brand: Phoenix Contact

Part#:3044636

Category:Terminal Blocks

Product Lifecycle:Active

428 in stock

Mar 14, 2025

Product description

Double-level terminal block, connection method: Screw connection, cross section: 0.14 mm² - 4 mm², AWG: 26 - 12, width: 5.2 mm, color: gray, mounting type: NS 35/7,5, NS 35/15

Product Details

Length
69.9 mm
Connection method
Screw connection
Surface flammability NFPA 130 (ASTM E 162)
passed
Conductor cross section solid max.
4 mm²
Degree of pollution
3
2 conductors with same cross section, stranded max.
1.5 mm²
Internal cylindrical gage
A3
Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, minimum
0.5 mm²
Permissible humidity (storage/transport)
30 % ... 70 %
Tightening torque max
0.6 Nm
ETIM 4.0
EC001329
UNSPSC 13.2
39121410
Insulating material
PA
Rated surge voltage
6 kV
Nominal voltage UN
500 V
Open side panel
Yes
Power frequency withstand voltage setpoint
1.89 kV
Tensile test result
Test passed
Result of voltage-drop test
Test passed
Test specification, oscillation, broadband noise
DIN EN 50155 (VDE 0115-200):2008-03

ASD level

1.857 (m/s2)2/Hz

Shock form

Half-sine

Number of shocks per direction

Fire protection for rail vehicles (DIN EN 45545-2) R22

HL 1 - HL 3

Fire protection for rail vehicles (DIN EN 45545-2) R23

HL 1 - HL 3

Height NS 35/15

72.5 mm

Conductor cross section AWG max.

2 conductors with same cross section, stranded min.

0.14 mm²

Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, minimum

0.14 mm²

Operating temperature

-60 °C ... 105 °C (max. short-term operating temperature 130°C)

ECLASS 10.0.1

27141120

ECLASS 6.0

27141100

UNSPSC 6.01

30211811

Color

gray

Area of application

Railway industry

Connection in acc. with standard

CSA

Shock protection test specification

DIN EN 50274 (VDE 0660-514):2002-11

Result of flexion and pull-out test

Test passed

Tractive force setpoint

60 N

Result of temperature-rise test

Test passed

Conductor cross section short circuit testing

4 mm²

Result of thermal test

Test passed

Conductor cross section flexible, with ferrule with plastic sleeve max.

2.5 mm²

2 conductors with same cross section, solid min.

0.14 mm²

Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, maximum

1.5 mm²

Ambient temperature (storage/transport)

-25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)

ECLASS 5.0

27141100

ECLASS 5.1

27141100

ETIM 6.0

EC000897

UNSPSC 11

39121410

Test directions

X-, Y- and Z-axis (pos. and neg.)

Shock duration

30 ms

Width

5.2 mm

Short circuit stability result

Test passed

Acceleration

Test specification, shock test

DIN EN 50155 (VDE 0115-200):2008-03

Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21))

125 °C

Specific optical density of smoke NFPA 130 (ASTM E 662)

passed

ECLASS 9.0

27141120

ETIM 7.0

EC000897

UNSPSC 21.0

39121410

Number of connections

Overvoltage category

III

Maximum power dissipation for nominal condition

0.77 W (the value is multiplied when connecting multiple levels)

Finger protection

guaranteed

Result of power-frequency withstand voltage test

Test passed

Conductor cross section tensile test

4 mm²

Tight fit on carrier

NS 35

Proof of thermal characteristics (needle flame) effective duration

30 s

Fire protection for rail vehicles (DIN EN 45545-2) R24

HL 1 - HL 3

End cover width

2.2 mm

Conductor cross section AWG min.

Conductor cross section flexible, with ferrule without plastic sleeve max.

2.5 mm²

China RoHS

Environmentally Friendly Use Period = 50 years

ECLASS 4.0

27141100

Requirements, voltage drop

≤ 3.2 mV

Oscillation, broadband noise test result

Test passed

Test duration per axis

5 h

Relative insulation material temperature index (Elec.; UL 746 B)

130 °C

Smoke gas toxicity NFPA 130 (SMP 800C)

passed

Fire protection for rail vehicles (DIN EN 45545-2) R26

HL 1 - HL 3

Height

64.4 mm

Conductor cross section flexible min.

0.14 mm²

2 conductors with same cross section, solid max.

1.5 mm²

Screw thread

Tightening torque, min

0.5 Nm

ECLASS 11.0

27141120

ECLASS 7.0

27141120

UNSPSC 20.0

39121410

Number of levels

Flammability rating according to UL 94

Insulating material group

Nominal current IN

24 A

Result of surge voltage test

Test passed

Checking the mechanical stability of terminal points (5 x conductor connection)

Test passed

Bending test turns

135

Result of tight fit on support

Test passed

Conductor cross section solid min.

0.14 mm²

Bending test rotation speed

10 rpm

Setpoint

1 N

Short-time current

0.48 kA

Ambient temperature (actuation)

-5 °C ... 70 °C

ECLASS 4.1

27141100

ETIM 3.0

EC000901

UNSPSC 19.0

39121410

UNSPSC 12.01

39121410

Nominal cross section

2.5 mm²

Maximum load current

28 A (in case of a 4 mm² conductor cross section, the maximum load current must not be exceeded by the total current of all connected conductors.)

Back of the hand protection

guaranteed

Bending test conductor cross section/weight

0.14 mm² / 0.2 kg

Test spectrum

Service life test category 1, class B, body mounted

Test frequency

f1 = 5 Hz to f2 = 150 Hz

Shock test result

Test passed

Static insulating material application in cold

-60 °C

Calorimetric heat release NFPA 130 (ASTM E 1354)

27,5 MJ/kg

Height NS 35/7,5

65 mm

Conductor cross section flexible max.

4 mm²

Conductor cross section flexible, with ferrule without plastic sleeve min.

0.14 mm²

Conductor cross section flexible, with ferrule with plastic sleeve min.

0.14 mm²

Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, maximum

1.5 mm²

Stripping length

9 mm

Ambient temperature (assembly)

-5 °C ... 70 °C

ETIM 2.0

EC000901

UNSPSC 7.0901

39121410

UNSPSC 18.0

39121410

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

3044636 Phoenix Contact
