3007217 Phoenix Contact Terminal Blocks

3007217 on Powermatic Associates
Phoenix Contact

Part#:3007217

Manufacturer:Phoenix Contact

Category:Terminal Blocks

Product Lifecycle:Active

25 in stock

Mar 14, 2025

Product description

Fuse modular terminal block, fuse type: Glass / ceramics / ..., connection method: Screw connection, cross section: 0.2 mm²- 4 mm², AWG: 24 - 12, nominal current: 32 A, nom. voltage: 400 V, width: 8.2 mm, fuse type: G / 6,3 x 32, mounting type: NS 35/7,5,

Product Details

  • Number of connections
    4
  • Rated surge voltage
    6 kV
  • Maximum load current
    32 A (Lower level)
  • Connection in acc. with standard
    CSA
  • Shock protection test specification
    DIN EN 50274 (VDE 0660-514):2002-11
  • Result of power-frequency withstand voltage test
    Test passed
  • Result of the test for mechanical stability of terminal points (5 x conductor connection)
    Test passed
  • Result of flexion and pull-out test
    Test passed
  • Result of thermal test
    Test passed
  • Surface flammability NFPA 130 (ASTM E 162)
    passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R26
    HL 1 - HL 3
  • Height NS 35/7,5
    79 mm
  • Conductor cross section solid min.
    0.2 mm²
  • Conductor cross section flexible max.
    4 mm²
  • Conductor cross section flexible, with ferrule with plastic sleeve max.
    4 mm²
  • Connection method
    Screw connection
  • Number of levels
    2
  • Flammability rating according to UL 94
    V0
  • Overvoltage category
    III
  • Fuse
    G / 6,3 x 32
  • Finger protection
    guaranteed
  • Result of tight fit on support
    Test passed
  • Result of temperature-rise test
    Test passed
  • Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21))
    130 °C
  • Smoke gas toxicity NFPA 130 (SMP 800C)
    passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R24
    HL 1 - HL 3
  • Height NS 35/15
    86.5 mm
  • Height NS 32
    84 mm
  • 2 conductors with same cross section, solid max.
    1.5 mm²
  • Cross section with insertion bridge, stranded max.
    2.5 mm²
  • Stripping length
    8 mm
  • Operating temperature
    -60 °C ... 105 °C (max. short-term operating temperature 130°C)
  • Permissible humidity (storage/transport)
    30 % ... 70 %
  • Nominal cross section
    4 mm²
  • Maximum power dissipation for nominal condition
    1.02 W (the value is multiplied when connecting multiple levels)
  • Nominal current IN
    32 A
  • Maximum load current (upper level)
    10 A
  • Fuse type
    Glass / ceramics / ...
  • Actuatiing forces on plug in or lever in fuse insert carriers
    Test passed
  • Insulating material group
    I
  • Bending test conductor cross section/weight
    0.2 mm² / 0.2 kg
  • Color
    black
  • Degree of pollution
    3
  • Maximum power dissipation
    max. 2.5 W (with single arrangement of the fuse terminal block in the event of overload)
  • Open side panel
    No
  • Result of surge voltage test
    Test passed
  • Compatibitity between modular fuse terminal block and fuse insert
    Test passed
  • Width
    8.2 mm
  • Note
    In the closed condition.
  • Insulating material
    PA
  • Nominal current IN (upper level)
    10 A
  • Testing the rated value of the power dissipation (exclusively short circuit protection)
    Test passed
  • Conductor cross section AWG min.
    24
  • Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, minimum
    0.5 mm²
  • Internal cylindrical gage
    A4
  • Screw thread
    M3
  • ECLASS 4.0
    27141100
  • ECLASS 6.0
    27141100
  • ETIM 6.0
    EC000899
  • UNSPSC 13.2
    39121410
  • UNSPSC 20.0
    39121410
  • Nominal voltage UN
    400 V
  • Relative insulation material temperature index (Elec., UL 746 B)
    130 °C
  • Calorimetric heat release NFPA 130 (ASTM E 1354)
    28 MJ/kg
  • Fire protection for rail vehicles (DIN EN 45545-2) R23
    HL 1 - HL 3
  • Conductor cross section AWG max.
    12
  • Conductor cross section flexible, with ferrule without plastic sleeve max.
    4 mm²
  • 2 conductors with same cross section, stranded min.
    0.2 mm²
  • Tightening torque max
    0.8 Nm
  • Ambient temperature (assembly)
    -5 °C ... 70 °C
  • ECLASS 11.0
    27141116
  • ECLASS 5.1
    27141100
  • ETIM 2.0
    EC000897
  • ETIM 7.0
    EC000899
  • UNSPSC 12.01
    39121410
  • Bending test turns
    135
  • Specific optical density of smoke NFPA 130 (ASTM E 662)
    passed
  • Conductor cross section solid max.
    4 mm²
  • Cross section with insertion bridge, solid max.
    4 mm²
  • 2 conductors with same cross section, stranded max.
    1.5 mm²
  • Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, maximum
    1.5 mm²
  • Ambient temperature (actuation)
    -5 °C ... 70 °C
  • ECLASS 4.1
    27141100
  • ECLASS 9.0
    27141116
  • UNSPSC 11
    39121410
  • UNSPSC 19.0
    39121410
  • Back of the hand protection
    guaranteed
  • Contact resistance
    Test passed
  • Static insulating material application in cold
    -60 °C
  • Conductor cross section flexible min.
    0.2 mm²
  • Conductor cross section flexible, with ferrule with plastic sleeve min.
    0.25 mm²
  • Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, maximum
    1.5 mm²
  • ECLASS 10.0.1
    27141116
  • ECLASS 5.0
    27141100
  • ETIM 3.0
    EC000899
  • UNSPSC 6.01
    30211811
  • UNSPSC 18.0
    39121410
  • Testing the rated value of the power dissipation (overload and short circuit Protection)
    Test passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R22
    HL 1 - HL 3
  • Length
    86.5 mm
  • Conductor cross section flexible, with ferrule without plastic sleeve min.
    0.25 mm²
  • 2 conductors with same cross section, solid min.
    0.2 mm²
  • Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, minimum
    0.25 mm²
  • Tightening torque, min
    0.5 Nm
  • Ambient temperature (storage/transport)
    -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
  • China RoHS
    Environmentally Friendly Use Period = 50 years
  • ECLASS 7.0
    27141116
  • ETIM 4.0
    EC000899
  • UNSPSC 7.0901
    39121410
  • UNSPSC 21.0
    39121410

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


Manufacturer warranty
