3047196 Phoenix Contact Terminal Blocks

3047196 on Powermatic Associates
Phoenix Contact

Part#:3047196

Manufacturer:Phoenix Contact

Category:Terminal Blocks

Product Lifecycle:Active

Only 4 left in stock. Order Now!

Mar 14, 2025

Product description

Partition plate, length: 69.7 mm, width: 2.2 mm, height: 52.5 mm, color: gray

Product Details

  • Static insulating material application in cold
    -60 °C
  • Surface flammability NFPA 130 (ASTM E 162)
    passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R24
    HL 1 - HL 3
  • Length
    69.7 mm
  • Ambient temperature (storage/transport)
    -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
  • Ambient temperature (actuation)
    -5 °C ... 70 °C
  • ECLASS 11.0
    27141133
  • ECLASS 4.0
    21011300
  • ECLASS 6.0
    27141100
  • ECLASS 9.0
    27141133
  • ETIM 6.0
    EC000886
  • UNSPSC 7.0901
    39121425
  • UNSPSC 18.0
    39121425
  • UNSPSC 21.0
    39121425
  • Relative insulation material temperature index (Elec., UL 746 B)
    130 °C
  • Specific optical density of smoke NFPA 130 (ASTM E 662)
    passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R22
    HL 1 - HL 3
  • Fire protection for rail vehicles (DIN EN 45545-2) R23
    HL 1 - HL 3
  • Fire protection for rail vehicles (DIN EN 45545-2) R26
    HL 1 - HL 3
  • Operating temperature
    -60 °C ... 105 °C (max. short-term operating temperature 130°C)
  • Ambient temperature (assembly)
    -5 °C ... 70 °C
  • Flammability rating according to UL 94
    V0
  • ECLASS 10.0.1
    27141133
  • ECLASS 4.1
    21011300
  • ECLASS 7.0
    27141133
  • ETIM 3.0
    EC000886
  • ETIM 7.0
    EC000886
  • UNSPSC 11
    39121425
  • UNSPSC 13.2
    39121425
  • Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21))
    125 °C
  • Calorimetric heat release NFPA 130 (ASTM E 1354)
    27,5 MJ/kg
  • Smoke gas toxicity NFPA 130 (SMP 800C)
    passed
  • Width
    2.2 mm
  • Height
    52.5 mm
  • Permissible humidity (storage/transport)
    30 % ... 70 %
  • China RoHS
    Environmentally friendly use period: unlimited = EFUP-e
  • ECLASS 5.0
    27141100
  • ECLASS 5.1
    27141100
  • ETIM 2.0
    EC000886
  • ETIM 4.0
    EC000886
  • UNSPSC 6.01
    30211828
  • UNSPSC 12.01
    39121425
  • UNSPSC 19.0
    39121425
  • UNSPSC 20.0
    39121425

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


Manufacturer warranty
