2206-1201 WAGO Terminal Blocks

Name: 2206-1201
Brand: WAGO
Price: 3.14 USD
Availability: InStock

Part#:2206-1201

Manufacturer:WAGO

Category:Terminal Blocks

Product Lifecycle:Active

24 in stock

Apr 1, 2025

Product description

2206-1201 WAGO - TOPJOB®S feedthrough terminal block with Push-buttons; rail mount; 2-conductor; 7.5 mm wide; gray

Product Details

Weight
9.967002621 g
Country Of Origin
Germany
HTS Code
85369010000
Width
0.295 inches, 7.5 millimeters
Weight
10.037 grams
Voltage
600 volts, 800 volts
Strip Length
0.59 inches, 15 millimeters
Package Type
Box
Mounting Type
DIN-35 Rail
Operating Temperature
105 degrees celsius
Insulation Material
Polyamide
Flammability Class
V0
Current
41 amperes, 50 amperes
Height
2.256 inches, 57.3 millimeters
Country of Origin
Germany
Conductor Size
10 millimeters, 8 american wire gauge
Conductor Material
Copper
Color
Gray
Actuator
Push-button

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2206-1201 on Powermatic Associates is $3.14. Order now.

$3.14

Your price can be lower.
Log in or Create account to check your discount

Stock:

Select Qty:

$3.14

$3.14 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
