3214262 Phoenix Contact Terminal Blocks

3214262 on Powermatic Associates
Phoenix Contact

Part#:3214262

Manufacturer:Phoenix Contact

Category:Terminal Blocks

Product Lifecycle:Active

80 in stock

Mar 15, 2025

Product description

Multi-level terminal block, With equipotential bonder, connection method: Screw connection, cross section: 0.14 mm² - 4 mm², AWG: 26 - 12, width: 5.2 mm, color: gray, mounting type: NS 35/7,5, NS 35/15

Product Details

  • Number of connections
    6
  • Rated surge voltage
    6 kV
  • Maximum power dissipation for nominal condition
    0.77 W (the value is multiplied when connecting multiple levels)
  • Maximum load current
    24 A (in case of a 4 mm² conductor cross section, the maximum load current must not be exceeded by the total current of all connected conductors.)
  • Back of the hand protection
    guaranteed
  • Power frequency withstand voltage setpoint
    1.89 kV
  • Nominal cross section
    2.5 mm²
  • Area of application
    Railway industry
  • Nominal current IN
    19 A (with a 2.5 mm² conductor cross section)
  • Result of surge voltage test
    Test passed
  • Bending test rotation speed
    10 rpm
  • Tight fit on carrier
    NS 32/NS 35
  • Conductor cross section short circuit testing
    2.5 mm²
  • Test spectrum
    Service life test category 2, bogie-mounted
  • Acceleration
    30g
  • Number of shocks per direction
    3
  • Number of levels
    3
  • Flammability rating according to UL 94
    V0
  • Insulating material group
    I
  • Nominal voltage UN
    500 V
  • Finger protection
    guaranteed
  • Bending test turns
    135
  • Test specification, oscillation, broadband noise
    DIN EN 50155 (VDE 0115-200):2018-05
  • Test directions
    X-, Y- and Z-axis (pos. and neg.)
  • Static insulating material application in cold
    -60 °C
  • Width
    5.2 mm
  • Height NS 35/7,5
    77.5 mm
  • Conductor cross section solid min.
    0.14 mm²
  • Conductor cross section AWG min.
    26
  • Conductor cross section flexible, with ferrule with plastic sleeve min.
    0.14 mm²
  • 2 conductors with same cross section, stranded min.
    0.14 mm²
  • Stripping length
    9 mm
  • Screw thread
    M3
  • Ambient temperature (storage/transport)
    -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
  • Ambient temperature (actuation)
    -5 °C ... 70 °C
  • ECLASS 4.1
    27141100
  • ECLASS 9.0
    27141120
  • ETIM 6.0
    EC000897
  • UNSPSC 11
    39121410
  • UNSPSC 18.0
    39121410
  • Color
    gray
  • Degree of pollution
    3
  • Connection in acc. with standard
    CSA
  • Shock protection test specification
    DIN EN 50274 (VDE 0660-514):2002-11
  • Result of power-frequency withstand voltage test
    Test passed
  • Short circuit stability result
    Test passed
  • Proof of thermal characteristics (needle flame) effective duration
    30 s
  • Test duration per axis
    5 h
  • Relative insulation material temperature index (Elec.; UL 746 B)
    130 °C
  • Specific optical density of smoke NFPA 130 (ASTM E 662)
    passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R22
    HL 1 - HL 3
  • Fire protection for rail vehicles (DIN EN 45545-2) R26
    HL 1 - HL 3
  • Length
    90 mm
  • Conductor cross section solid max.
    4 mm²
  • Conductor cross section AWG max.
    12
  • Conductor cross section flexible, with ferrule with plastic sleeve max.
    2.5 mm²
  • 2 conductors with same cross section, stranded max.
    1.5 mm²
  • Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, maximum
    1.5 mm²
  • Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, maximum
    1.5 mm²
  • Operating temperature
    -60 °C ... 105 °C (max. short-term operating temperature 130°C)
  • Ambient temperature (assembly)
    -5 °C ... 70 °C
  • ECLASS 11.0
    27141120
  • ETIM 3.0
    EC000897
  • ETIM 4.0
    EC000897
  • UNSPSC 6.01
    30211811
  • UNSPSC 21.0
    39121410
  • Insulating material
    PA
  • Overvoltage category
    III
  • Open side panel
    Yes
  • Checking the mechanical stability of terminal points (5 x conductor connection)
    Test passed
  • Short-time current
    0.3 kA
  • ASD level
    6.12 (m/s2)2/Hz
  • Shock form
    Half-sine
  • Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21))
    130 °C
  • Calorimetric heat release NFPA 130 (ASTM E 1354)
    28 MJ/kg
  • Fire protection for rail vehicles (DIN EN 45545-2) R23
    HL 1 - HL 3
  • End cover width
    2.2 mm
  • Connection method
    Screw connection
  • Conductor cross section flexible max.
    4 mm²
  • Conductor cross section flexible, with ferrule without plastic sleeve max.
    2.5 mm²
  • 2 conductors with same cross section, solid max.
    1.5 mm²
  • Two conductors with the same cross section stranded, with ferrule and without plastic sleeve, minimum
    0.14 mm²
  • Internal cylindrical gage
    A3
  • Tightening torque max
    0.6 Nm
  • ECLASS 10.0.1
    27141120
  • ECLASS 4.0
    27141100
  • ECLASS 5.1
    27141100
  • ETIM 7.0
    EC000897
  • UNSPSC 7.0901
    39121410
  • UNSPSC 13.2
    39121410
  • UNSPSC 20.0
    39121410
  • Result of temperature-rise test
    Test passed
  • Result of thermal test
    Test passed
  • Test frequency
    f1 = 5 Hz to f2 = 250 Hz
  • Shock duration
    18 ms
  • Surface flammability NFPA 130 (ASTM E 162)
    passed
  • Smoke gas toxicity NFPA 130 (SMP 800C)
    passed
  • Fire protection for rail vehicles (DIN EN 45545-2) R24
    HL 1 - HL 3
  • Height NS 35/15
    85 mm
  • Conductor cross section flexible min.
    0.14 mm²
  • Conductor cross section flexible, with ferrule without plastic sleeve min.
    0.14 mm²
  • 2 conductors with same cross section, solid min.
    0.14 mm²
  • Two conductors with the same cross section, flexible, with TWIN ferrules, with plastic sleeve, minimum
    0.5 mm²
  • Tightening torque, min
    0.5 Nm
  • Permissible humidity (storage/transport)
    30 % ... 70 %
  • China RoHS
    Environmentally Friendly Use Period = 50 years
  • ECLASS 5.0
    27141100
  • ECLASS 6.0
    27141100
  • ECLASS 7.0
    27141120
  • UNSPSC 12.01
    39121410
  • UNSPSC 19.0
    39121410

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


Manufacturer warranty
