3361482
Festo
Product Lifecycle: Active
Alt. Part#: HGPL-14-80-A-B
parallel gripper HGPL-14-80-A-B Size: 14, Stroke per gripper jaw: 80 mm, Max. replacement accuracy: < 0,2 mm, Max. angular gripper jaw backlash ax,ay: < 0,2 deg, Max. gripper jaw backlash Sz: < 0,05 mm
parallel gripper HGPL-14-80-A-B Size: 14, Stroke per gripper jaw: 80 mm, Max. replacement accuracy: < 0,2 mm, Max. angular gripper jaw backlash ax,ay: < 0,2 deg, Max. gripper jaw backlash Sz: < 0,05 mm
Product details
- Size14
- Pneumatic gripper repetition accuracy< 0.03 mm
- Number of gripper jaws2
- Gripper functionParallel
- Symbol00991894
- Min. opening time at 6 bar286 ms
- Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)
- Maximum torque on gripper jaw, Mz static35 Nm
- Relubrication interval for guidance elements5 MioCyc
- Housing materialAluminum Smooth anodized
- Max. gripper jaw angular play ax, ay< 0.2 deg
- Rotational symmetry≤ 0.2 mm
- Type codeHGPL
- Mode of operationDouble-acting
- Total gripping force at 6 bar, opening126 N
- Corrosion resistance class (CRC)2 - Moderate corrosion stress
- Gripping force per gripper jaw at 6 bar, closing79 N
- Maximum torque on gripper jaw, Mx static35 Nm
- Type of mountingWith internal thread and centering sleeve Via through-hole and centering sleeve
- Gripper jaw materialSteel Hardened
- Max. interchangeability< 0.2 mm
- Max. gripper jaw backlash Sz< 0.05 mm
- Position sensingFor proximity sensor
- Min. closing time at 6 bar270 ms
- Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]
- Mass moment of inertia21.93 kgcm²
- Maximum torque on gripper jaw, My static35 Nm
- Max. mass per external gripper finger80 g
- Stroke per gripper jaw80 mm
- Mounting positionAny
- DesignTwin piston Gear rack/pinion
- Operating pressure3 bar ... 8 bar
- Total gripping force at 6 bar, closing158 N
- Gripping force per gripper jaw at 6 bar, opening63 N
- Product weight720 g
- Note on materialsFree of copper and PTFE RoHS-compliant
- Max. operating frequency of pneumatic gripper< 1 Hz
- Ambient temperature5 °C ... 60 °C
- Maximum force on gripper jaw Fz, static500 N
- Pneumatic connectionM5
This part can ship within 24 hours
$1,913.29
