536248 Festo Pneumatic Actuators

Name: 536248
Brand: Festo

Part#:536248

Alt. Part#:ADN-20-40-I-P-A

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Apr 1, 2025

Product description

compact cylinder ADN-20-40-I-P-A Per ISO 21287, with position sensing and internal piston rod thread Stroke: 40 mm, Piston diameter: 20 mm, Piston rod thread: M6, Cushioning: P: Flexible cushioning rings/plates at both ends, Assembly position: Any

Product Details

Operating pressure
0.6 bar ... 10 bar
Cushioning
Elastic cushioning rings/pads at both ends
Symbol
00991217
Conforms to standard
ISO 21287
Variants
Piston rod at one end
Moving mass at 0 mm stroke
30 g
Note on materials
RoHS-compliant
Stroke
40 mm
Piston rod end
Internal thread
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Theoretical force at 6 bar, advancing
188 N
Additional moving mass per 10 mm stroke
6 g
Pneumatic connection
M5
Material of cylinder barrel
Wrought aluminum alloy Smooth anodized
Piston diameter
20 mm
Mounting position
Any
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Additional weight per 10 mm stroke
21 g
Type of mounting
Optionally: With accessories
Seals material
TPE-U(PUR)

Piston rod thread

Type code

ADN

Position sensing

For proximity sensor

Mode of operation

Double-acting

Ambient temperature

-20 °C ... 80 °C

Basic weight with 0 mm stroke

131 g

Cover material

Aluminum Anodized

Operating medium

Compressed air as per ISO 8573-1:2010 [7:4:4]

Impact energy in the end positions

0.2 J

Theoretical force at 6 bar, retracting

141 N

Piston rod material

High-alloy steel

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
