536316 Festo Pneumatic Actuators

Name: 536316
Brand: Festo

Part#:536316

Alt. Part#:ADN-50-40-A-P-A

Manufacturer:Festo

Category:Pneumatic Actuators

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Apr 1, 2025

Product description

compact cylinder ADN-50-40-A-P-A Per ISO 21287, with position sensing and external piston rod thread Stroke: 40 mm, Piston diameter: 50 mm, Piston rod thread: M12x1,25, Cushioning: P: Flexible cushioning rings/plates at both ends, Assembly position: Any

Product Details

Mounting position
Any
Symbol
00991217
Ambient temperature
-20 °C ... 80 °C
Stroke
40 mm
Conforms to standard
ISO 21287
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Moving mass at 0 mm stroke
140 g
Type of mounting
Optionally: With accessories
Seals material
TPE-U(PUR)
Operating pressure
0.6 bar ... 10 bar
Type code
ADN
Piston rod end
External thread
Mode of operation
Double-acting
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Theoretical force at 6 bar, advancing
1178 N
Additional moving mass per 10 mm stroke
16 g
Piston rod thread
M12x1.25
Position sensing
For proximity sensor
Impact energy in the end positions
1 J
Basic weight with 0 mm stroke
540 g

Pneumatic connection

G1/8

Material of cylinder barrel

Wrought aluminum alloy Smooth anodized

Piston diameter

50 mm

Cushioning

Elastic cushioning rings/pads at both ends

Variants

Piston rod at one end

Corrosion resistance class (CRC)

2 - Moderate corrosion stress

Theoretical force at 6 bar, retracting

1057 N

Note on materials

RoHS-compliant

Piston rod material

High-alloy steel

Additional weight per 10 mm stroke

51 g

Cover material

Aluminum Anodized

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
