601403 Lapp Industrial Automation Components

601403 on Powermatic Associates
Lapp

Part#:601403

Manufacturer:Lapp

Category:Industrial Automation Components

Product Lifecycle:Active

24 in stock

Mar 15, 2025

Product description

601403 Lapp - ÖLFLEX 190 3G2.5 14/3C

Product Details

  • Voltage
    600 volts
  • Stranding
    Class 5 Fine Wire
  • Operating Temperature
    -40 degrees celsius, 105 degrees celsius
  • Jacket Material
    Thermoplastic Polymer
  • Jacket Color
    Gray
  • Insulation Material
    PVC
  • Gauge
    14 american wire gauge
  • Conductor Material
    Finely Stranded Bare Copper
  • Bend Radius
    4 X Cable Diameter
  • MANUFACTURER PART NUMBER
    601403
  • WEIGHT LBS/MFT
    93
  • UL STYLE / STANDARD
    UL 13 UL 2277
  • TRAY RATINGS
    UL TC-ER
  • STANDARDS/APPROVALS
    UL Approved CSA Approved CE Approved
  • ATTRIBUTES
    UL Oil Res I/IISunlight resistant Direct burialNFPA 79
  • DYNAMIC TEMPERATURE RATING
    -13°F to +194°F-25°C to +90°C
  • STATIC TEMPERATURE RATING
    -40°F to +221°F-40°C to +105°C
  • TEMPERATURE
    -13°F to +194°F -25°C to +90°C
  • VOLTAGE
    600V
  • INSULATION
    PVC
  • NOMINAL OD (MM)
    9
  • SERIES
    ÖLFLEX® 190 / 190 CY
  • AWG/GAUGE
    14
  • JACKET MATERIAL
    Thermoplastic Polymer
  • SHIELDING
    Unshielded
  • CONDUCTOR STRANDING
    Stranded
  • CONDUCTOR COLOR
    Black with white printing plus green/yellow ground
  • NOMINAL OD (IN)
    0.356
  • CONDUCTOR MATERIAL
    Bare copper
  • NUMBER OF CONDUCTORS
    3
  • JACKET COLOR
    Gray

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


About the product

Cable, Flexible, ÖLFLEX 190, 14 AWG/3C, 600V, UL TC-ER, UL AWM, CSA AWM FT4
