175825 Festo Proximity Sensors

175825 on Powermatic Associates
Festo

Part#:175825

Alt. Part#:SMTSO-8E-NS-M12-LED-24

Manufacturer:Festo

Category:Proximity Sensors

Product Lifecycle:Active

Product description

proximity sensor SMTSO-8E-NS-M12-LED-24 Electric, contactless, NPN, for drives with T-slot, without mounting kit, with M12 plug, welding field resistant design. Design: for T-slot, Authorisation: RCM Mark, CE mark (see declaration of conformity): to EU di

Product Details

  • Design
    for T-slot
  • Switching output
    NPN
  • On time
    ≤ 38 ms
  • Short-circuit protection
    Pulsed
  • Electrical connection
    3-pin Plug
  • Max. tightening torque
    0.5 Nm
  • Housing material
    Wrought aluminum alloy High-alloy stainless steel
  • Type code
    SMTSO
  • Electrical connection 1, connection technology
    M12x1 A-coded as per EN 61076-2-101
  • Electrical connection 1, number of pins/wires
    3
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Special features
    Welding field resistant Resistant to welding spatter
  • Max. output current
    200 mA
  • Max. switching capacity DC
    6 W
  • Overload protection
    Available
  • Product weight
    10 g
  • Resistance to interference from magnetic fields
    45 - 65 Hz Alternating magnetic field
  • Electrical connection 1, connection type
    Plug
  • Certification
    RCM compliance mark
  • Measuring principle
    Magneto-inductive
  • Voltage drop
    ≤ 3 V
  • Connection outlet orientation
    Transverse
  • Electrical connection for input 1, connection pattern
    00995573
  • Repetition accuracy
    0.2 mm
  • Ambient temperature
    -25 °C ... 70 °C
  • Switch-off time
    ≤ 20 ms
  • Reverse polarity protection
    for all electrical connections
  • Switching status indication
    LED yellow
  • Electrical connection 1, type of mounting
    Screw-type lock
  • Symbol
    00991150
  • Note on materials
    Free of copper and PTFE
  • Switching element function
    N/O contact
  • Residual current
    ≤ 0.01 mA
  • DC operating voltage range
    10 V ... 30 V
  • Type of mounting
    Clamped in T slot Can be inserted in slot from above
  • Degree of protection
    IP65 IP67

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

175825 Related Documents

175825 DataSheet.pdf
