VS2AN5R Banner Proximity Sensors

Name: VS2AN5R
Brand: Banner

Banner VS2AN5R VS2 Series: Receiver; Range: 1.2 m max; Input: 12-24 V dc; Output: Complementary NPN Light Operate; 2 m (6.5 ft) Cable

Part#:VS2AN5R

Manufacturer:Banner

Alt. Part#:55402

Product Lifecycle:Active

Get a quick Quote!

VS2 Series: Receiver; Range: 1.2 m max; Input: 12-24 V dc; Output: Complementary NPN Light Operate; 2 m (6.5 ft) Cable

About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the VS2AN5R Banner price in the box on the right side or send a quick quote.

Product Details

Weight
45.3592 g
Country Of Origin
MX
Feature: Chemical Resistant
No
IO Link
No
DeviceNet
No
Feature: Audible
No
Feature: Hazardous Area
No
Feature: Encapsulated
No
Feature: Timing (Hold/Delay)
No
Opposed Mode Emitter/Receiver
Receiver
Indicator
LEDs
Barrel Diameter (mm)
N/A
Adjustments
N/A
Lens Material
MABS
Max Op. Relative Humidity [%]
80% @ 50°C
NEMA Rating
NEMA 6
IP Rating
IP67
Special Feature: Remote Teach
No
Repeatability (µs)
100
Number of Pins
3

Delay at Power-up (ms)

100

Sensing Beam Wavelength

940

Special Feature: Water Detection

Special Feature: Intrinsically Safe

Max Op. Temp. (°C)

Output response time (ms)

1 ON/0.5 OFF

Operation

Light Operate

Connection

Cable

Min Op. Temp. (°C)

-20

Quick Disconnect Type

No QD

Power Supply/Supply Voltage

10-30 V dc

Outputs

NPN

Sensing Mode (Detailed)

Receiver

Input/Output

Discrete

Primary Housing Material

Thermoplastic

Housing Style

Rectangular

Max Sensing Distance (mm)

3000

Sensing Mode (General)

Opposed

Sensing Beam

Visible Red or IR

Power

Cable Length (m)

Shape

Rectangular

Sensing distance

Light Color

Infrared (IR)

Primary brand

Banner Engineering

Sub-range name

VS2 series

Digital outputs

1 x digital output (NPN transistor)

Compliant with standard(s)

Supply voltage (DC)

10Vdc-30Vdc (12Vdc / 24Vdc nom.)

Design

through-beam system / opposed mode

Connection type

Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads

Main function

Sensor (Photo-electric)

Wavelength

940 nm

Degree of protection

IP67 NEMA 6

Material

thermoplastic housing MABS lns.

Ambient air temperature for operation

-20...+55 °C

Functions

Photo-electric sensor receiver green LED (power ON) amber LED (light sensed)

Order code / Manufacturer SKU

55402

Response time

(ON) 1ms / 0.001 s(OFF) 0.5ms / 0.0005 s

Operating mode

Light-ON NO (Normally Open)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

VS2AN5R Description

Banner Engineering VS2AN5R is a photo-electric sensor designed with a thermoplastic housing MABS lns. and offers a degree of protection rated at IP67 NEMA 6, making it suitable for various industrial environments. It operates within an ambient air temperature range of -20 to +55 °C and features a Light-ON NO (Normally Open) operating mode. This sensor is equipped with 1 x digital output (NPN transistor) and boasts a quick response time of 1ms for ON and 0.5ms for OFF. It comes pre-wired with a 6.5ft / 2m cable terminated with bare end flying leads for easy installation. The rectangular-shaped sensor operates at a wavelength of 940 nm, emitting infrared (IR) light, and requires a supply voltage of 10Vdc-30Vdc, with 12Vdc / 24Vdc nominal. Designed as a through-beam system or opposed mode, it has a sensing distance of up to 3m. The VS2AN5R is part of the VS2 series and functions as a photo-electric sensor (receiver alone).
