SLLVP23-1190 Banner Safety Light Curtains

Banner Engineering SLLVP23-1190 is a safety light curtain from the LS Basic heavy-duty safety light curtains series designed for hand detection with a resolution of 23mm. This unit features an emitter and receiver pair housed in yellow aluminum with acrylic lens and zinc end caps. It offers a protective height of 1190mm and operates with a supply voltage of 24Vdc. The SLLVP23-1190 operates within an ambient air temperature range of -20 to +55°C and is rated with a degree of protection of IP65 and IP67, ensuring durability in various environmental conditions. It has a net width of 36mm, a net height of 1193mm, and a net depth of 45mm. The light curtain provides a sensing distance from 10cm to 8m and utilizes infrared light with a wavelength of 850nm. It features two digital outputs (24Vdc; 500mA; sourcing; redundant OSSD solid-state outputs), one digital output for emitter fault (24Vdc; sourcing/PNP transistor; 70mA), and two digital inputs (10Vdc-30Vdc; 30mA) for position ID and scan code. The response time is 19.2ms, and the connection is facilitated through a wiring chamber.
