S30RW3LP Banner Proximity Sensors

S30RW3LP on Powermatic Associates
Banner

Part#:S30RW3LP

Manufacturer:Banner

Category:Proximity Sensors

Alt. Part#:33362

Product Lifecycle:Active

Get a quick Quote!

EZ-BEAM S30 Series: Polarized Retro; Range: 6 m; Input: 20-250 V ac; Output: SPST Solid-state Dark Operate; 2 m (6.5 ft) Cable

About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the S30RW3LP Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    199.126888 g
  • Country Of Origin
    US
  • Feature: Audible
    No
  • DeviceNet
    No
  • Feature: Hazardous Area
    No
  • IO Link
    No
  • Feature: Chemical Resistant
    No
  • Feature: Encapsulated
    Yes
  • Opposed Mode Emitter/Receiver
    N/A
  • Feature: Ecolab Certified
    Yes
  • Feature: Timing (Hold/Delay)
    No
  • Indicator
    LEDs
  • Barrel Diameter (mm)
    30
  • Adjustments
    N/A
  • Lens Material
    Acrylic
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • NEMA Rating
    NEMA 6P
  • Number of Pins
    3
  • Repeatability (µs)
    4000
  • IP Rating
    IP67
  • Delay at Power-up (ms)
    100
  • Special Feature: Water Detection
    No
  • Special Feature: Remote Teach
    No
  • Special Feature: Intrinsically Safe
    No
  • Output response time (ms)
    16
  • Max Op. Temp. (°C)
    70
  • Operation
    Dark Operate
  • Min Op. Temp. (°C)
    -40
  • Quick Disconnect Type
    No QD
  • Connection
    Cable
  • Power Supply/Supply Voltage
    20-250 V ac
  • Outputs
    Solid-State AC Switch
  • Power
    AC
  • Sensing Mode (Detailed)
    Polarized
  • Max Sensing Distance (mm)
    6000
  • Input/Output
    Solid-State AC Switch
  • Housing Style
    Barrel
  • Sensing Beam
    Visible Red LED
  • Primary Housing Material
    Thermoplastic
  • Sensing Mode (General)
    Retroreflective
  • Cable Length (m)
    2
  • Functions
    Polarized photo-electric sensor green LED (power ON) yellow LED (output state)
  • Main function
    Sensor (Photo-electric)
  • Light Color
    Visible red
  • Primary brand
    Banner Engineering
  • Product series / family name
    EZ-BEAM series
  • Supply voltage (AC)
    20Vac-250Vac (200Vac / 220Vac / 240Vac nom.)
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Response time
    16ms / 0.016 s
  • Ambient air temperature for operation
    -40...+70 °C
  • Sub-range name
    S30 series
  • Shape
    Cylindrical threaded/barrel
  • Degree of protection
    IP69K NEMA 6P
  • Design
    retro-reflective mode
  • Wavelength
    680 nm
  • Material
    thermoplastic housing
  • Sensing distance
    6m
  • Thread size
    M30
  • Digital outputs
    1 x digital output (Solid-state AC output)
  • Order code / Manufacturer SKU
    33362
  • Operating mode
    Dark-ON
  • Compliant with standard(s)
    cULus Listed cCSAus CE

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

S30RW3LP Description

Banner Engineering S30RW3LP is a polarized photo-electric sensor from the S30 series designed in a retro-reflective mode. This sensor features a thermoplastic housing and is pre-wired with a 6.5ft / 2m cable that terminates with bare end flying leads. It operates on a supply voltage range of 20Vac-250Vac, with nominal voltages of 200Vac, 220Vac, and 240Vac. The S30RW3LP can function within an ambient air temperature range of -40 to +70°C and is rated with a degree of protection of IP67 NEMA 6P, indicating a high level of protection against dust and water ingress. Its shape is an M30 cylindrical threaded/barrel, and it includes 1 x digital output (Solid-state AC output). The sensing distance of this sensor is 6m, and it emits a visible red light with a wavelength of 680 nm. The response time is 16ms / 0.016 s, and it operates in a Dark-ON mode. The thread size for mounting is M30.

Related documents S30RW3LP Specs

S30RW3LP 116158.pdf
