1688395 Phoenix Contact Data & Networking Devices

Name: 1688395
Brand: Phoenix Contact

Part#:1688395

Category:Data & Networking Devices

Product Lifecycle:Active

28 in stock

Mar 14, 2025

Product description

D-SUB contact insert, shell size 1, with 9 signal contacts, female type of contact, screw connection, straight, for panel mounting frame and sleeve housing with IP67 protection

Product Details

Weight
13.98 g
UNSPSC 6.01
31261501
ECLASS 5.0
27260700
ETIM 4.0
EC000438
UNSPSC 11
31261501
UNSPSC 21.0
39121522
ECLASS 4.0
27260700
ECLASS 6.0
27261200
ETIM 7.0
EC000438
UNSPSC 19.0
39121522
ECLASS 5.1
27261200
ETIM 2.0
EC000437
ECLASS 7.0
27440302
UNSPSC 12.01
31261501
UNSPSC 20.0
39121522
REACh SVHC
Lead 7439-92-1
ECLASS 4.1
27260700
ETIM 3.0
EC000437
ETIM 6.0
EC000438
UNSPSC 7.0901
31261501

UNSPSC 13.2

39121522

UNSPSC 18.0

39121522

ECLASS 10.0.1

27440205

Insulation resistance

≥ 5000 MΩ

ECLASS 9.0

27440205

Connection method

Screw connection

Contact surface material

Gold

Height

12.6 mm

Mounting type

Screw mounting

AWG solid min.

AWG solid max.

Type

D-SUB 15

Housing surface material

tin-plated

Number of positions

Overvoltage category

Housing material

Steel

Length

49 mm

Rated current

5 A

ECLASS 11.0

27440223

Degree of pollution

Conductor cross section

0.14 mm² ... 0.5 mm²

Ambient temperature (operation)

-20 °C ... 80 °C

Width

31 mm

Rated voltage (III/3)

60 V

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Manufacturer warranty

1688395 Phoenix Contact
