NPORT 5450 Moxa Data & Networking Devices

Product Details

• Warranty Period
  5 years
• Time
  773,682 hrs
• Medical
  EN 60601-1-2 Class B, EN 55011
• Standards
  Telcordia (Bellcore) Standard TR/SR
• Maritime
  DNV
• EMI
  CISPR 32, FCC Part 15B Class A
• EMC
  EN 55032/35
• Safety
  UL 62368-1
• EMS
  IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV; IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m; IEC 61000-4-4 EFT: Power: 2 kV; Signal: 0.5 kV; IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV; IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m; IEC 61000-4-8
• Dimensions (without ears)
  158 x 103 x 33 mm (6.22 x 4.06 x 1.30 in)
• Ambient Relative Humidity
  5 to 95% (non-condensing)
• Storage Temperature (package included)
  -40 to 75°C (-40 to 167°F)
• Operating Temperature
  0 to 55°C (32 to 131°F)
• Installation
  Desktop; DIN-rail mounting (with optional kit); Wall mounting
• Interactive Interface
  LCD panel display; Push buttons for configuration
• Dimensions (with ears)
  181 x 103 x 33 mm (7.14 x 4.06 x 1.30 in)
• Automatic Reboot Trigger
  Built-in WDT
• Alert Tools
  Built-in buzzer and RTC (real-time clock)
• Housing
  Metal
• Weight
  740 g (1.63 lb)
Input Voltage
12 to 48 VDC, 24 VDC for DNV
Power Connector
1 removable 3-contact terminal block(s); Power input jack
No. of Power Inputs
2
Terminator for RS-485
120 ohms
Input Current
365 mA @ 12 VDC
Flow Control
RTS/CTS (RS-232 only); DTR/DSR (RS-232 only)
RS-485-4w
Tx+, Tx-, Rx+, Rx-, GND
Parity
None, Even, Odd, Space, Mark
RS-232
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-485 Data Direction Control
ADDC (automatic data direction control)
RS-485-2w
Data+, Data-, GND
Pull High/Low Resistor for RS-485
1 kilo-ohm, 150 kilo-ohms
Data Bits
5, 6, 7, 8
RS-422
Tx+, Tx-, Rx+, Rx-, GND
Stop Bits
1, 1.5, 2
Operation Modes
Real COM; TCP Server; TCP Client; UDP; Ethernet Modem; Pair Connection; Reverse Telnet; Disabled
No. of Ports
4
Encryption
HTTPS; AES-128; RSA-1024; SHA-1; SHA-256
Baudrate
Supports standard baudrates (unit=bps): 50, 75, 110, 134, 150, 300, 600, 1200, 1800, 2400, 4800, 7200, 9600, 19200, 38400, 57600, 115200, 230.4k, 460.8k, 921.6k
Serial Standards
RS-232; RS-422; RS-485
Connector
DB9 male
Security Protocols
HTTPS (TLS 1.2); SNMPv3
Time Management
SNTP
Android API
Android 3.1.x and later
Authentication
Local database
Virtual Machine
VMWare ESXi (Windows 11 / 10) ; VMware Fusion (Windows on macOS 10.12 to 11.x); Parallels Desktop (Windows on macOS 10.12 to 11.x)
Management
ARP; BOOTP; DHCP Client; DNS; HTTP; HTTPS; ICMP; IPv4; LLDP; Rtelnet; SMTP; SNMPv1/v2c; TCP/IP; Telnet; UDP
Windows Real COM Drivers
Windows 11/10/8.1/8/7/Vista/XP/ME/98/95; Windows Server 2022/2019/2016/2012 R2/2012/2008 R2/2008/2003/2000/NT; Windows Embedded CE 5.0/6.0, Windows XP Embedded
Magnetic Isolation Protection
1.5 kV (built-in)
Filter
IGMP v1/v2
Configuration Options
Telnet Console; Windows Utility; Web Console (HTTP/HTTPS)
Arm®-based Platform Support
Linux Kernel 5.x/4.x;
Fixed TTY Drivers
macOS Versions: 10.12 to 10.15, 11.x; ; SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
Linux Real TTY Drivers
Kernel Versions: 6.x, 5.x, 4.x, 3.x, 2.6.x, and 2.4.x
10/100BaseT(X) Ports (RJ45 connector)
1
