560703 Festo Pneumatic Components

Product Details

• Reset method
  Pneumatic spring
• Sealing principle
  Soft
• Flow direction
  Non-reversible
• Electrical connection
  2-pin Plug
• Pneumatic connection 3
  Sub-base
• Width
  12 mm
• Operating pressure
  2 bar ... 8 bar
• Pneumatic working port
  Sub-base
• Switching time off
  10 ms
• Pilot medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Corrosion resistance class (CRC)
  0 - No corrosion stress
• Note on materials
  RoHS-compliant
• Nominal width
  2.1 mm
• Actuation type
  Electrical
• Operating voltage
  24V DC
• Degree of protection
  IP40
• Mounting position
  Any
• Type of control
  Pilot-controlled
• Symbol
  00991183
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
Pneumatic connection 1
Sub-base
Housing material
Wrought aluminum alloy
Valve function
3/2, closed, monostable
Lap
Overlap
Standard nominal flow rate
180 l/min
Design
Piston gate valve
Exhaust air function
With flow control option
Manual override
Non-detenting
On switching time
12 ms
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Temperature of medium
-5 °C ... 50 °C
Type code
VOVG
Coil characteristics
24 V DC: 1.0 W
Ambient temperature
-5 °C ... 50 °C
Pneumatic connection 2
M5
Seals material
FPM NBR
