10837 Festo Pneumatic Components

Product Details

• Operating voltage
  Via solenoid coil, to be ordered separately
• Width dimension
  32 mm
• Valve function
  3/2, open, monostable
• Actuation type
  Electrical
• Operating pressure
  1.5 bar ... 8 bar
• Certification
  c UL us - Recognized (OL)
• Mounting position
  Any
• Switching time off
  41 ms
• Coil characteristics
  See solenoid coil, to be ordered separately
• Storage temperature
  -20 °C ... 60 °C
• Standard nominal flow rate
  800 l/min
• Reset method
  Mechanical spring
• Nominal width
  7 mm
• Flow direction
  Non-reversible
• On switching time
  14 ms
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Pneumatic working port
  1/4 NPT
• Degree of protection
  IP65
• Sealing principle
  Soft
• Max. positive test pulse with 0 signal
  2200 µs
Ambient temperature
-5 °C ... 40 °C
Venting hole connection
M5
Pneumatic connection 3
1/4 NPT
Lap
Underlap
Width
30.5 mm
Design
Plate seat
Type code
MOFH
Manual override
Detenting
Type of control
Pilot-controlled
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Temperature of medium
-10 °C ... 60 °C
Pneumatic connection 1
1/4 NPT
Pneumatic connection 2
1/4 NPT
Note on materials
RoHS-compliant
Exhaust air function
With flow control option
Symbol
00995429
Max. negative test pulse on 1 signal
3700 µs
Corrosion resistance class (CRC)
1 - Low corrosion stress
Product weight
320 g
Pilot exhaust air port 82
M5
Pneumatic connection 33
1/4 NPT
Type of mounting
Optionally: With through-hole
Seals material
NBR
Electrical connection
Via F coil, to be ordered separately
Pneumatic connection 11
1/4 NPT
Housing material
Die-cast aluminum
