551400 Festo Proximity Sensors

Product Details

• Electrical connection 1, connection technology
  M8x1 A-coded as per EN 61076-2-104
• Conforms to standard
  EN 60947-5-2
• Note on materials
  Free of copper and PTFE RoHS-compliant
• Switching output
  NPN
• Electrical connection
  3-pin Rotatable thread
• Cable characteristic
  Standard + cable chain
• Type code
  SIES
• Electrical connection for input 1, connection pattern
  00991155
• Design
  for T-slot
• Certification
  RCM compliance mark c UL us - Listed (OL)
• Reduction factors
  Aluminum = 0.62 Steel St 37 = 1.0
• Switching element function
  N/O contact
• Cable length
  10 m
• Type of mounting
  Flush with T-slot Can be inserted in slot from above
• Contamination level
  3
• KC characters
  KC EMC
• Symbol
  00991703
• Repetition accuracy under constant conditions
  <= 0.05 mm, approach from the side
• Max. switching frequency
  4500 Hz
• Reverse polarity protection
  for all electrical connections
Connection outlet orientation
Longitudinal
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
Insulation voltage
50 V
Selection of sensor version
Special design
Electrical connection 1, type of mounting
Screw-type lock
Rated operating distance
1.5 mm
Short-circuit protection
Pulsed
DC operating voltage range
10 V ... 30 V
Size
Slot 8
Degree of protection
IP65 IP67
Selection of additional sensor information
For T-slot
Electrical connection 1, connection type
Cable with plug
Electrical connection 1, number of pins/wires
3
CE marking (see declaration of conformity)
As per EU EMC directive
Ambient temperature
-25 °C ... 70 °C
Max. output current
150 mA
Idle current
≤ 10 mA
Connector cable test conditions
Flexural strength: as per Festo standard Cable chain: 5 million cycles, bending radius 75 mm
Material of cable sheath
TPE-U(PU)
Housing material
Brass, nickel-plated High-alloy stainless steel
Electrical output
NPN
Switching status indication
LED yellow
Surge resistance
0.8 kV
