34436 Festo Directional Control Valves

34436 on Powermatic Associates
Festo

Part#:34436

Alt. Part#:VLX-2-1-MS

Manufacturer:Festo

Category:Directional Control Valves

Product Lifecycle:Active

Product description

pneumatic valve VLX-2-1-MS 2/2-way function, pneumatically actuated, brass version. Design structure: Diaphragm valve, Type of actuation: pneumatic, Sealing principle: soft, Assembly position: Any, Mounting type: Line installation

Product Details

  • Sealing principle
    Soft
  • Nominal width
    25 mm
  • Type of mounting
    Line installation
  • Medium pressure
    1 bar ... 10 bar
  • Reset method
    Pneumatic spring
  • Medium
    Filtered compressed air, 200 µm filter mesh
  • Standard nominal flow rate
    14000 l/min
  • Product weight
    1010 g
  • Type code
    VLX
  • Mounting position
    Any
  • Flow direction
    Non-reversible
  • Pilot medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Material of screws
    High-alloy stainless steel
  • Design
    Diaphragm valve
  • Valve function
    2/2, closed, monostable
  • Ambient temperature
    -10 °C ... 60 °C
  • Actuation type
    Pneumatic
  • Fitting connection
    G1
  • Type of control
    Pilot-controlled
  • Temperature of medium
    -10 °C ... 80 °C
  • Material number of screw
    1.4301
  • Exhaust air function
    Without flow control option
  • Symbol
    00991371
  • Housing material
    Brass

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

34436 Related Documents

34436 DataSheet.pdf
