171164 Festo Proximity Sensors

171164 on Powermatic Associates
Festo

Part#:171164

Alt. Part#:SMEO-8E-M12-LED-24

Manufacturer:Festo

Category:Proximity Sensors

Product Lifecycle:Active

Product description

proximity sensor SMEO-8E-M12-LED-24 Electric, with reed contact, for drives with T-slot, without mounting kit, with M12 plug. Design: for T-slot, Conforms to standard: EN 60947-5-2, Authorisation: RCM Mark, CE mark (see declaration of conformity): to EU d

Product Details

  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Switching output
    Contact-based, bipolar
  • Max. switching frequency
    800 Hz
  • Max. switching capacity DC
    10 W
  • Reverse polarity protection
    no
  • Product weight
    9 g
  • Housing material
    Wrought aluminum alloy High-alloy stainless steel
  • Electrical connection 1, type of mounting
    Screw-type lock
  • Electrical connection 1, connection type
    Plug
  • Electrical connection 1, number of pins/wires
    3
  • Symbol
    00991148
  • Conforms to standard
    EN 60947-5-2
  • Max. output current
    500 mA
  • Overload protection
    Not available
  • DC operating voltage range
    12 V ... 30 V
  • Tightening torque
    0.5 Nm
  • Switching status indication
    LED yellow
  • Contamination level
    3
  • Type code
    SMEO
  • Electrical connection 1, connection technology
    M12x1 A-coded as per EN 61076-2-101
  • Design
    for T-slot
  • Certification
    RCM compliance mark
  • Measuring principle
    Magnetic reed
  • Switching element function
    N/O contact
  • Short-circuit protection
    no
  • Min. switching capacity AC
    10 VA
  • Type of mounting
    With accessories
  • Material of cable sheath
    PUR
  • Surge resistance
    0.8 kV
  • Electrical connection for input 1, connection pattern
    00995862
  • Repetition accuracy
    0.2 mm
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Ambient temperature
    -40 °C ... 60 °C
  • On time
    ≤ 0.5 ms
  • Switch-off time
    0.03 ms
  • Operating voltage range AC
    12 V ... 30 V
  • Connection outlet orientation
    Transverse
  • Material of pin contacts
    Brass
  • Degree of protection
    IP65 IP67

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
