VS8ANFF15Q3

Banner

Product Lifecycle: Active

Banner Engineering VS8ANFF15Q3 is a fixed-field photo-electric sensor designed with a thermoplastic housing and a polymethyl methacrylate (PMMA) lens. It features a polyurethane (PUR) cable and offers a degree of protection rated at IP67, making it suitable for operation in ambient air temperatures ranging from -20 to +60°C. This sensor operates in a Light-ON mode and includes 1 x digital output (NPN transistor) with a response time of 0.5ms / 0.0005 s. It is equipped with a pre-wired 7.5" / 200mm pigtail terminated with a 3-pin Pico-style M8 connector. The rectangular-shaped sensor emits a visible red light with a wavelength of 650 nm and operates on a supply voltage of 10Vdc-30Vdc (12Vdc / 24Vdc nom.). It features a background suppression system and has a sensing distance of 2 to 15m. This sensor is part of the VS8 series.

VS8ANFF15Q3

Banner Engineering VS8ANFF15Q3 is a fixed-field photo-electric sensor designed with a thermoplastic housing and a polymethyl methacrylate (PMMA) lens. It features a polyurethane (PUR) cable and offers a degree of protection rated at IP67, making it suitable for operation in ambient air temperatures ranging from -20 to +60°C. This sensor operates in a Light-ON mode and includes 1 x digital output (NPN transistor) with a response time of 0.5ms / 0.0005 s. It is equipped with a pre-wired 7.5" / 200mm pigtail terminated with a 3-pin Pico-style M8 connector. The rectangular-shaped sensor emits a visible red light with a wavelength of 650 nm and operates on a supply voltage of 10Vdc-30Vdc (12Vdc / 24Vdc nom.). It features a background suppression system and has a sensing distance of 2 to 15m. This sensor is part of the VS8 series.

VS8 Background Suppression Sensor -- Datasheet.pdf

Product details

VS8 Background Suppression Sensor -- Datasheet.pdf

IO LinkNo
Feature: AudibleNo
DeviceNetNo
Feature: Chemical ResistantNo
IndicatorLEDs
Feature: Timing (Hold/Delay)No

Barrel Diameter (mm)N/A

Opposed Mode Emitter/ReceiverN/A

Feature: Hazardous AreaNo

Feature: EncapsulatedNo

Lens MaterialPMMA

AdjustmentsN/A

NEMA RatingN/A

Number of Pins3

IP RatingIP67

Delay at Power-up (ms)300

Repeatability (µs)N/A

Sensing Beam Wavelength650

Special Feature: Water DetectionNo

Special Feature: Intrinsically SafeNo

Special Feature: Remote TeachNo

Output response time (ms)0.5

Max Op. Temp. (°C)60

OperationLight Operate

Quick Disconnect TypeM8 (Pico)

Min Op. Temp. (°C)-20

Power Supply/Supply Voltage10-30 V dc

ConnectionPigtail QD

OutputsNPN

Sensing Mode (General)Proximity

Sensing Mode (Detailed)Background Suppression (Fixed)

Sensing BeamVisible Red LED

Max Sensing Distance (mm)15

PowerDC

Small Visible SpotLED

Primary Housing MaterialPUR

Input/OutputDiscrete

Housing StyleRectangular

Main functionSensor (Photo-electric)

Supply voltage (DC)10Vdc-30Vdc (12Vdc / 24Vdc nom.)

Primary brandBanner Engineering

Sensing distance2...15m

ShapeRectangular

Operating modeLight-ON

Order code / Manufacturer SKU803452

Sub-range nameVS8 series

Connection typePre-wired with 7.5" / 200mm pigtail terminated with 3-pin Pico-style M8 connector

FunctionsFixed-field photo-electric sensor green LED (power ON) yellow LED (output state)

Wavelength650 nm

Response time0.5ms / 0.0005 s

Ambient air temperature for operation-20...+60 °C

Designbackground suppression system

Digital outputs1 x digital output (NPN transistor)

Compliant with standard(s)cULus CE

Light ColorVisible red

Degree of protectionIP67

Materialthermoplastic housing PMMA lns. PUR (cable)
